swaco shale shaker machine

Product Overview

Description

shale shaker



. All shaker screens can be fit on shakers by wedge blocks or hooks. According to clients’ requirements it can be linear motion or balanced elliptical motion, even dual motion one. Please find following features on shale shaker:



1. All material is high quality national standard carbon steel . Initially assured products quality

2. Stress reliving on shaker basket and other main parts. Getting longer service life

3. Sand blasting before painting the high anti-corrosive marine paint. Better appearance and better quality

4. Adopted famous vibration motors(Martin, Oli, or Ita-Vibras).High vibrating strength better filtration effect

5. Compact structure small foot print. Easy to handle and installation. Convenient to operate

6. A few spare parts. Easy to maintain and lower running cost

7. Competitive price with high cost-efficient





Shale shaker Parameter

Model	Hunter-D3	Hunter-D4	Hunter-D3B
Vibration Track	Linear	Linear	BEM
Motor Power	1.72KWx2	1.94KWx2
Vibrating Strength	>6 G	>6.5 G
Double Amplitude	5~6mm
Treating Capacity	120m3/h 528GPM	140m³/h  615GPM	140m³/h  615GPM
Deck Angle	-1~5°
Power System	380V/50HZ, 460V/60HZ
Shaker Screen	720×1050×3	720×1050×4	720×1050×3
Decibels	<85db
Weight	1600KG	1800KG	1950KG
Dimension	2800X1600X1500	3500X1600X1500	2800X1600X1500
Remark	Dual tandem or triple tandem shakers available
