DEUTZ ENGINE BF8L513C BF12L513FLC F8L413 F10L413 F12L413
DEUTZ BF8L513C air cooled diesel engine for construction machine
Power: 213-235kw 2300rpm
DEUTZ license
SHANGHAI STONE DIESEL ENGINE CO.,LTD
DEUTZ 413 Diesel Engine for Construction machine
Model | Displacement | Power Rating | Peak Torque | Weight | Dimensions (mm) |
F6L413F | 9.572 L | 77-141 kw 1500-2500rpm | 613 N.m | 605kg | 1047x1038x860 |
F8L413F | 12.763 L | 103-188kw 1500-2500rpm | 760 N.m | 770kg | 1211x1038x860 |
BF8L413F/C | 12.763 L | 129-235kw 1500-2500rpm | 980 N.m | 950kg | 1202x1168x1156 |
F10L413F | 15.953 L | 129-235kw 1500-2500rpm | 1020 N.m | 940kg | 1412x1038x937 |
F12L413F | 19.144 L | 154-282kw 1500-2500rpm | 1226 N.m | 1120kg | 1575x1038x956 |
BF12L413F | 19.144 L | 194-353kw 1500-2500rpm | 1470 N.m | 1250kg | 1573x1192x1050 |
BF12L413FC | 19.144L | 270-386kw 1500-2500rpm | 1695 N.m | 1400kg | 1580x1192x1140 |
Deutz 513 diesel engine for construction machine
Model | Displacement | Power Rating | Peak Torque | Weight | Dimensions (mm) |
F8L513 | 13.382 L | 103-188kw 1500-2300rpm | 890 N.m | 770kg | 1211x1038x860 |
BF8L513C | 12.763 L | 137-243kw 1500-2300rpm | 1200 N.m | 950kg | 1190x1168x1156 |
BF8L513 | 12.763 L | 213-235kw 2300rpm | 1170 N.m | 920kg | 1201x1148x1042 |
BF8L513LC | 13.744 L | 192-265kw 1500-2300rpm | 1506 N.m | 970kg | 1202x1188x1156 |
BF10L513 | 15.953 L | 172-278kw 1500-2300rpm | 1400 N.m | 1140kg | 1272x1138x1067 |
BF12L513 | 19.144 L | 206-334kw 1500-2300rpm | 1650 N.m | 1250kg | 1380x1573x1192 |
BF12L513C | 19.144 L | 230-406kw 1500-2100rpm | 1900 N.m | 1400kg | 1580x1192x1140 |
