Best price 7 color rotogravure printing machine
- Category: Rotogravure Printing Machines >>>
- Supplier: Wenzhou Zhuding Machine Co. Ltd.
Share on (1936599307):
Product Overview
Description
Banner
Product Description
Performance and Characteristics
This machine is used for cellophane, BOPP, PET, PVC, PE, aluminium foil and web with good printing performance for multi-color continuous printing.
1) The whole machine is fixed by permutation combination, according to the customers' requirement, the printing color unit can be increased or decreased and the cover printing mechanism can be added as well.
2)The traction and rewinding adopt frequency conversion and synchronous speed regulation.
3) Each unit of computer flashed system is controlled by separate micro-processor. It can adjust the flashed deviation quickly and precisely.
4) General shaft style installment.
5) Display of flashed deviation, correcting of system comprehensive deviation as superdifference alarming function.
6) Double photoelectrical checking improves the whole checking and speed adjustment.
7) Rewinding and discharging traction are adopted with full automatic, tension controller and magnetic powder brake and clutch to control.
8) The winding adopts frequency conversion traction, while the pressing roller adopts pneumatic componevts to control.
9) Printing roller and discharging traction pressing roller are both adopted with pneumatic unit to control.
10) Pneumatic back pressure shifting blade.
11) Ink circulating system.
12) Gas expansion type loading and unloading shaft.
13) Unwinding and rewinding are both double working mechanisms to meet non-stop roll-change.
1) The whole machine is fixed by permutation combination, according to the customers' requirement, the printing color unit can be increased or decreased and the cover printing mechanism can be added as well.
2)The traction and rewinding adopt frequency conversion and synchronous speed regulation.
3) Each unit of computer flashed system is controlled by separate micro-processor. It can adjust the flashed deviation quickly and precisely.
4) General shaft style installment.
5) Display of flashed deviation, correcting of system comprehensive deviation as superdifference alarming function.
6) Double photoelectrical checking improves the whole checking and speed adjustment.
7) Rewinding and discharging traction are adopted with full automatic, tension controller and magnetic powder brake and clutch to control.
8) The winding adopts frequency conversion traction, while the pressing roller adopts pneumatic componevts to control.
9) Printing roller and discharging traction pressing roller are both adopted with pneumatic unit to control.
10) Pneumatic back pressure shifting blade.
11) Ink circulating system.
12) Gas expansion type loading and unloading shaft.
13) Unwinding and rewinding are both double working mechanisms to meet non-stop roll-change.
Model | ZD-ASYD8600 | ZD-ASYD8800 | ZD-ASYD81000 |
Printing length | 240-1100 mm | 240-1100 mm | 240-1100 mm |
Printing width | 600 mm | 800 mm | 1000 mm |
Color number | 1-8 | 1-8 | 1-8 |
Printing speed | ≤110 m/min | ≤110 m/min | ≤110 m/min |
Precision of register | ≤0.12mm | ≤0.12mm | ≤0.12mm |
Gross power | 46 kw | 58 kw | 72 kw |
Weight of machine | Approx 9000 kg | Approx 10000 kg | Approx 12000 kg |
Dimensions (L×W×H)(mm) | 10800×2050×2720 | 10800×2050×2720 | 10800×2050×2720 |
Company Information
Shipping & Packaging
FAQ
1. Q:How long will your engineer reach our factory?
A:Within one week after everything ready (machine arrival your factory, non woven material, power source, air compressor etc.Prepared)
2. Q:How many days will you finish installing ?
A:We will finish installation and training within 15 days.
3. Q:What should we charge for your engineer?
A:You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.
4. Q:How long is your machine's warranty period?
A: All our machine have one year guarantee for electricity parts and two years guarantee for mechanism, starting from finished installation.
5. Q:How could you do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
6. Q:How could you do after one year warranty period?
A:We also can do service for you, but you need pay salary for our technicians 80USD/day for each person.
7. Q:Does your engineer understand English?
A:Our engineers understand a little English. All our engineers have more than five years machine installation experience.
8. Q:Can you help us find any engineer in our location?
A:Of course, we will check and inform you as soon as possible.
9. Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
A:Within one week after everything ready (machine arrival your factory, non woven material, power source, air compressor etc.Prepared)
2. Q:How many days will you finish installing ?
A:We will finish installation and training within 15 days.
3. Q:What should we charge for your engineer?
A:You should charge for the cost of our engineer's air tickets, hotel, food, and also their salary 80USD one day per person.
4. Q:How long is your machine's warranty period?
A: All our machine have one year guarantee for electricity parts and two years guarantee for mechanism, starting from finished installation.
5. Q:How could you do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
6. Q:How could you do after one year warranty period?
A:We also can do service for you, but you need pay salary for our technicians 80USD/day for each person.
7. Q:Does your engineer understand English?
A:Our engineers understand a little English. All our engineers have more than five years machine installation experience.
8. Q:Can you help us find any engineer in our location?
A:Of course, we will check and inform you as soon as possible.
9. Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finishing installation. In case you have any problem, you can contact our sales at any time. Our engineers will take a solution video according your description.
