3 Phase Induction Motor 220V 2HP/1.5KW AC Motor

Product Overview

Description

3 Phase Induction Motor 220V 2HP/1.5KW AC Motor

Y Series three-phase induction motor, adopting the national unified design, has reached the international advanced level of 90's. It can replace Y series induction motor anad possess sophisticated features such as new construction, good-looking appearance, low noise, low vibration, economization on power and materials consumption,etc.



Introduction:



1.Features: totally enclosed,fan-cooling,squirrel cage type and noted for their novel design,compact structure , high efficiency ,  large torque,excellent starting performance,low noise, and easy maintenance,etc.Adopting F class insulation according to international practice, motor's safety and reliability can be greatly enhanced



2.Applications:machine tools,pumps,fans,conveyors,mixers,agriculture machinery,machines for food processing.



3.Operating conditions:

•  Ambient temperature: -15°C<0<40°C
•  Altitude: not exceeding 1000 m
•  Rated voltage:380v or any voltage between 220v-760v
•  Rated frequency: 50 Hz, 60 Hz
•  Protection class: IP44, IP54, IP55
•  Insulation class: B , F
•  Cooling method: IC0141
•  Duty: S1 (continuous)
•  Connection : start-connection for up to3 kw,  delta-connection for 4 kw and above







Product images:
