C70B stainless steel general open top wagon

Load capacity

70t

Dead weight

23.8t

Axle load

23t+2% -1%

Volume

77m³

Specific volume

1.1m³/t

Equivalent length

1.3

Dead weight coefficient

0.33

Load per meter of track

6.71t/m

Minimum railway curve radius

145m

Commercial operation speed

120km/h

Center of gravity height of empty wagon

1085mm

Braking distance(Full wagon, urgence)

≤1400m

Braking leverage of whole wagon

7.8

Braking ratio

Full wagon:  17.9%

Empty wagon: 24.1%

Limit

Up to specification of GB146.1-1983 “Limit of standard gauge railway rolling stock ”

Wagon length

13976mm

Wagon distance

9210mm

Wagon maximum width

3242mm

Wagon maximum height (empty)

3143mm
