Pharmaceutical / Medicine Stainless Steel Container / Tank
- Category: >>>
- Supplier: Shanghai Ritai Medicine Equipment Project Co. Ltd.
Share on (1945482707):
Product Overview
Description
Product Description
Ritai is a professional manufacturer for all kind of stainless steel tanks, such as mixing tank, reactor, storage tank, fermentor, bioreactor and CIP tank.
Ritai, which has three factories, is one of the biggest manufacturers of stainless steel tanks in China.
Name: Pharmaceutical / Medicine Stainless Steel Container / Tank
Application:
It is applied to liquid preparation and various water treatment process in purgative area,such as infusion solution, injection
solution, eye drop, oral liquid and blood preparation. It is used for mixing liquid products in pharmacy, chemistry, biology, food and drinks fields.
We have different kinds of agitators
Bottom magnetic agitator with propeller impellers. The range of its rotating speed is 50-400rpm or 50-800rpm. It is applied to many products, such as eyedrop, injection, CIP liquid, and water, media culture, or simialr products , etc.
Top mechancial agitator with propeller impellers. The range of its rotating speed is fixed 71rpm or adjustable 20-200rpm, or we can make it according to your special requirements. This kind of agitator is applied to mix syrup, injection, blood, oral liquid, and
culture media, etc.
Top mechanical agitator with anchor or frame impellers, its rotating speed is from 10-70rpm. It use for mixing higher viscosity, supension and it can be used for sediment or oral liquid, etc.
Top emusification homogenizer, its max speed is 2900rpm for small vessels, 1480rpm is for bigger tanks. This kind of agitator
has the highest viscosity, and it is used for suspension, oil, fat emulsification, etc.
Bottom emusification homogenizer, its parameters are the same as the top emusification homogenizer. Certainly, it is used for suspension, oil, fat emulsification, etc.
One tank can install one agitator, if our clients have special requirements, the tank can install two agitators together.
Product technical description of pharmaceutical / medicine stainless steel tank / container:
Specification: 10L~30000L
Material: SS316L or SS304
Surface finish: inside surface is Ra0.28~0.4μm by mechanical polish. (passivation or electropolish are optional). Outside surface is Ra0.6~0.8μm by satin finish.
Pressure: ATM or pressure vessel (-0.1~1Mpa)
Structure: Single layer vessel, vessel with jacket, vessel with jacket and insulation
Jacket type: dimple jacket, full jacket, or coil jacket
Insulation material: rock wool
Components can be equipped as requests:
Standard components: manhole or handhole, sight glass, cleaning ball
Optional components:
vent filter with Pall cartridge or Chinese brand cartridge
temp. gauge, display on the gauge directly on the vessel
temp sensor pt100, digital display on the control cabinet by instrument
temp sensor with control for heating and cooling
level gauge with digital display of the instrument on control cabinet
load cell
valves
Manufacture standard for pressure vessel: ASME with U stamp, PED 97/23/EC with CE mark, GB150-2011
| Working volume | Inner diameter | Outer diameter | Vessel height | Total volume |
| 30L | 400mm | 500mm | 400mm | 44L |
| 50L | 400mm | 500mm | 600mm | 69L |
| 100L | 500mm | 600mm | 650mm | 130L |
| 200L | 600mm | 700mm | 1000mm | 250L |
| 300L | 700mm | 800mm | 1250mm | 370L |
| 500L | 900mm | 1050mm | 1150mm | 650L |
| 1000L | 1100mm | 1250mm | 1480mm | 1260L |
| 1500L | 1200mm | 1350nmm | 1700mm | 1780L |
| 2000L | 1300mm | 1500mm | 1980mm | 2200L |
| 3000L | 1500mm | 1700mm | 2150mm | 3400L |
| 4000L | 1600mm | 1750mm | 2630mm | 4000L |
| 8000L | 1900mm | 2100mm | 3200mm | 8300L |
| The above dimension is only for reference, we can make up to 50000L , and we can make special dimension according to client specific requirement. | ||||
Packaging & Shipping
Packaging: plywood case Shipping: by sea or by air
Our Services
We offer design, customization, manufacture, installation, and maintenance services, etc.
Company Information
Shanghai Ritai Medicine Equipment Project Co., Ltd. mainly specializes in innovation and development of sanitary stainless steel pressure vessels, atmospheric pressure vessels, fermenters, valves and piping system which are widely used in the following fields, such as pharmacy, biology, chemistry, food and drinks industry.
Shanghai Ritai is qualified to design and manufacture pressure vessels with the certificates of ASME, PED 97/23/EC, NB, and ISO9001:2008
FAQ
Frequently Asked Questions:
1.Where are your production locations?
1.1 No.39, Xinjin Road, Qingpu District, Shanghai, 201712, China
1.2. No.3766,Qingzhao Road,Qingpu District, Shanghai,201712,China
2. List of your manufacturing machinery:
Cutting machine, rolling machine, polishing machine, welding machine, detecting machine, etc.
3. How is the machinery servied and maintained?
By professional engineer
4. Is measuring and inspection equipment continuously calibrated?
Yes
