TLC1640 car radio antenna with stainless steel mast

Product Overview

Description



car radio antenna with stainless steel mast





Specification:TLC1640

1. SUS304 antenna mast can extend to length 1200mm

2. Cable length 2500mm

3. Frequency: FM 87.5-108MHz,AM 520-1620MHz

4. Polarization: Vertical

5. Type of Radiation:Omni Directinal

5. Connector: ISO DIN plug

6. Universal front or rear fender and side mount



Coaxial cable parameters:
1. Cable pull force: 30KG without deformation
2. Cable parameter: 3C-2V 75Ω coaxial cable
3. Impedance: 75Ω±3Ω
4. Static capacity: 69PF/m±3PF/m



Technical Requirements
1. Working temperature: -30℃~+80℃
2. Storage temperature: -40℃~+90℃



Passing main tests:



1. Appearance inspection: No plastic shrink or wrinkle

2. ISO DIN connector pull force: >=49N by puller

3. Signal reception: more than 10 channels with clear voice, no noise

4. Salt spraying: more than 96 hours without any rust.



5. Drop test: free drop from 1 meter without any damage.

6. High temperature test:Under 80℃±2℃ for 72 hour, no deformation, crack, color fading and break off.

7. Low temperature test: Under -40℃±2 for 72 hour, no deformation, crack, color fading and break off.

8. Vibration test: 10-55Hz vibration for 24hours, no deformation, loose, crack or break off



Company certification:
