hydraulic wrench from Hangzhou Penad, hydraulic torque wrench factory

Product Overview

Description

Characters:

1.Square hydraulic torque wrench,high quality with good performance.

2.Precision Machined - Increases accuracy, durability and repeatability.

3.360° Swivel Fittings (Patented) - Allow hose movement without hose binding. Stainless steel with fewer moving parts - a great improvement over competitors’ delicate design. (Dual plane swivel fittings shown on wrench above.)

4.Coated - All exposed parts to resist corrosion

5.Calibrated - Every tool is function tested and calibrated to ±0 .03 accuracy



Details of products:

Products Drawings:

Selection Chart:

SELECTION CHART OF PDTA SERIES  HYDRAULIC TORQUE WRENCH
MODEL	07PDTA	1PDTA	3PDTA	5PDTA	8PDTA	10PDTA	15PDTA	20PDTA	25PDTA	35PDTA
TORQUE(N.m)	112-1120	183-1837	451-4512	752-7528	1078-10780	1551-15516	2062-20627	2666-26664	3572-34725	4866-48666
BOLT SIZE(M)	14-30	16-36	22-48	27-56	30-64	36-72	39-80	42-90	48-100	64-120
WEIGH(KGS)	1.8	2	4	7	9.1	13.1	18	25	31	45
L1(mm)	110.8	130	166	198	213	231	270	295	314	355
L2(mm)	139.3	182	241	281	308	336	400	443	464	489
H1(mm)	42	50	68	80	90	100	110	120	137	153
H2(mm)	65.8	72	95	123	130	141	179	182	200	217
H3(mm)	76.2	99	130	155	171	187	201	228	255	290
H4(mm)	108.1	144	176	198	216	230	244	268	295	330
R1(mm)	20.5	26	34	39	47	51	55	59	67	79
R2(mm)	68.3	99	134	152	171	174	195	250	251	271
SQUARE DRIVE	3/4"	3/4″	1″	1-1/2″	1-1/2″	1-1/2″	2-1/2"	2-1/2″	2-1/2″	2-1/2″



Packing and shipping:

Wrenches packed in metal case, then in carton.

Pumps packed in double layer carton.

Our service:

Our provides one year guarantee for all the hydraulic products. We promise if there is any dysfunction of the hydraulic cylinder during the quality warranty not by outside force, we will replace a new one for free. Any quality defects reported by customers will be responded within 24 hours.

FAQ:

Q: Can you do OEM?
A: Yes, we can.
Q: How about the MOQ?
A: 1set

Q: How about the delivery time?
A: Normally, 1-2 wrokings days. But it depends on your order quantity.
Q: How about the warranty?
A: 1 year.
Q: What certificate do your product have?
A: We have CE, ISO 9001:2000, and CE
Q: Where is your loading port?
A: Ningbo or Shanghai, China port.
Q: Are you a manufactuer or trading company?
A: We are a manufacturer specialize in hydraulic tools for more than 10 years.
