large capacity ss conical ethanol storage tank for sale

Product Overview

Description

Wine storage tank is used for storing alcohol/ethanol with variety capacity.  It's made by high quality stainless steel material (304/316L) , with bright and smooth surface. It also can be designed to have a conical bottom or with insulation layer as the customer's requirement.



Basic configuration



l Manhole(oval/ round/ rectangle)

l Breathing valve

l bottom manhole

l Sampling valve

l Legs

l Thermometer

l Level indicator

l Inlet/ Outlet



Technical table

Volume:cbm	Diameter: mm	Shell height: mm	Total height:mm	Leg: Piece	Cooling area(sqm)
1	950	1500	2400	3	1.5
2	1200	1830	2950	3	2.2
3	1500	1830	3000	3	4.5
4	1600	2000	3250	3	5.0
5	1700	2440	3700	4	5.3
10	1900	3660	5050	4	8.5
15	2000	4880	5950	4	12.5
20	2300	4880	6100	4	15.0
25	2400	5490	6715	4	18.0
30	2500	6100	7350	4	20.0
40	2900	6100	7395	4
50	3200	6100	7450	6
60	3300	7000	7845	/
70	3500	7320	8195	/
80	3800	7320	8235	/
100	4000	8540	9480	/
120	4200	8540	9510	/
150	4700	8820	9955	/









container , flat rack container or saddle



After-sale service: engineer available to service machinery overseas

Provide operations overseas by our technician for large-scaled projects

Prettech works in the field of stainless steel tank production, trade and service.

Our product range: fermentation tank, storage tank, bright tank,wine barrel in the industries of food & beverage, dairy, pharmacy and chemicals.

We provide services of technology and design, consultation,OEM, maintenace, overseas operation.

Find more information about us in www.prettech.cn
