ABE 3 beams infrared barrier motion detector alarm 100m~200m alert active infrared indoor/outdoor 3 beams detector

Model

ABE50/100/150/200/250 three beams active infrared

Outdoor alarm distance

50/100/150/200/250m

Indoor alarm distance

150/300/450/600/750m

Beam of light

3

Lamp-house

Infrared digital pulse

Inducing rate

35—700ms

Alarm output-normal

Normal close and normal open(NC&NO), contact point capability, AV/DC   30V/0.5A

Alarm output-BUS

MA BUS constant current carrier wave

Operating voltage

DC 13.8—24V,AC 11—18V

Operating current

70mA

Long lifespan current  mode

40mA

Operating temperature

-25°C—55°C

Operating humidity

5%—95% (RH)

Visibility

≥5m

Anti-dismantle output

Normal close(NC), contact point  capability: AV/DC   24V/0.5A

Horizontal angle adjustable

180°(±90°)

Vertical angle adjustable

±10°

Shell material

 PC
