Automatic Silverware Packing Machine with Napkin KT-350X

Product Description




Main Performance And Structure Features:

1.Dual frequency conversion control, Bag length can be set and cut in one step, saving time and film.

2.Interface features easy and quick setting and operation.

3.Self failure diagnosis, clear failure display.

4.High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.

5.Temperature independent PID control, more suitable for packaging different materials.

6.Positioned stop function, without sticking knife or wasting film.

7.Simple driving system, reliable working, convenient maintenance.

8.All control is realized through software, easy for function adjusting and technical upgrade.



Optional Accessories:

1:Date Coder                                                    2:Touchable Screen               3:Automatic Punching Device

4:Alternative sealing patterns and notch         5:Auto labeling device            6:Deoxidizer chute device

7:Gas flushing device                                      8:Alcohol spraying device       9:Auto feeder



Specification (With the product size selection models):

 Type KT-250X KT-350X KT-450X KT-600X KT-700X
 Film Width Max.250MM Max.350MM  Max.450MM  Max.600MM Max.700MM
 Bag Length 65-280MM 65-330MM  150-450MM  160-500MM  180-600MM
 Bag Width 30-110mm 50-160mm 50-180mm 100-280mm 100-330mm
 Product Height Max.45mm Max.65mm Max.80mm Max.110mm Max.110mm
 Packing Speed 40-230bag/min 40-230bag/min 40-150bag/min 20-150bag/min 20-130bag/min
 Power 220V 50/60HZ 2.4KW 220V 50/60HZ 2.8KW 220v 50/60HZ 2.8KW

 220v 50/60HZ

2.8KW

 220V 50/60HZ

2.8KW

 Machine Size(mm) 3920x670x1320 4020x720x1320 4150x820x1450 4300x920x1460 4380x980x1480
 Machine Weight 500kg 550kg 650kg 680kg 720kg



Automatic Silverware Packing Machine with Napkin KT-350X






 Bag Type:



bag type.jpg





Other Hot Products

 -

6



Packaging & Shipping

Packaging:

We use the wooden case to pack our packing machine.



Shipping:
Upon receipt of payment , delivery date will be in 10-35days,
By Air, by Sea or by Express (DHL etc)
Shipment cost will depend on the destination, shipment way and the weight of the goods



Our Services

 The machine will have one year warranty . During the warranty year if any of the parts broken not by man-made .  We will free charge to replace the new one to you . The warranty will begin after the machine send out we received  the B/L



Company Information




Contact Us

Kindly Reminder:

Please let us know the follow packing details when you offer,so that we can check if this model is suitable for your case.Thank you in advance.
1. Product details
2. Bag width,bag length
3. Bag shape
4. Packing film material
5. Machine frame
