hot sale cocoa bean grinding machine cacao nib colloid mill 0086 13298176400

Product Overview

Description

Aloe/pepper/apple/cocoa bean grinding machine









This bone machine is maily used to crush material into paste, jam in food, medicine, chemical area.

The raw material could be peanut, sesame, coconut, mustard, almond etc.
The final butter is more fine and this machine have big capacity.



 Main application:



This machine is suitable for pharmaceutical, food, chemical and other industries wet material superfine grinding, can play all kinds of  semiliquids and emulsion liquid material crushing, milk, homogeneous mixing.



Working principle:

1.The machine is through the different geometric shape of the stator and the rotor under high rotation speed in the relative motion, through the shear, grinding, the high frequency vibration and get broken.



2.Broken room has three way grinding zone, level 1 for thick grinding zone, level 2 for fine grinding zone, level 3 for superfine grinding zone, through the adjustment of the stator clearance, can have the effect to a desired effect (also can be broken superfine processing cycle).



3.The machine has compact structure, smooth operation, the noise is small, corrosion resistant, easy cleaning, maintenance is convenient wait for a characteristic.



Technical Parameters of Bone Mud Machine :



Model	SJM-50	SJM-80	SJM-110	SJM-130	SJM-180	SJM-240	SJM-300
fineness(µm)	50-100	50-100	100-200	100-200	100-200	100-200	60-200
Output(t/h)	0.005-0.03	0.1-0.5	0.3-1.2	0.5-2	0.8-6	4-15	6-20
Power	1.1/380v,1.5/220v	4/380v	7.5/380v	11/380v	18.5/380v	37/380v	55/380v
Weight(kg)	50	210	300	400	450	1300	1600
Dimension(m)	0.53*0.26*0.58	0.4*0.41*0.93	0.7*0.43*1	0.99*0.44*1.1	0.99*0.49*1.1	1.32*0.5*1.28	1.44*0.63*1.42
