C45N 2 Pole MCB merlin gerin circuit breaker

Electrical Features

Standard

IEC/EN60898-1

Rated Current In

A

63 80 100 125

Poles

1P 2P 3P 4P

Rated Voltage Ue

V

230/400

Insulation Voltage Ui

V

500

Rated Frequency

Hz

50/60HZ

Rated Breaking Capacity

A

10000

Rated Impulse Withstand Voltage(1.2/50)Uimp

V

6000

Dielectric Test Voltage At And Ind. Freq For 1 Min

Kv

2

Pollution Degree

2

Themo-Magnetic Release Characteristic

B C D

Mechanical Features

Electrical Life

8000

Mechanical Life

20000

Contact Position Indicator

Yes

Protection Degree

IP20

Reference Temperature Of Setting Of Thermal Element

°C

30

Ambient Temperature(With Daily Average ≤35°C)

°C

-5~+40

Storage Temperature

°C

-25.+70

Installation

Terminal Connection Type

Terminal Size Top/Bottom For Cable

Mm² Awg

25

18-3

Terminal Size Top/Bottom For Busbar

Mm² Awg

25

18-3

Tightening Torque

N*M IN-IBS

3.0

22

Mounting

On Din Rail Fn60715(35mm) By Means Of Fast Clip Device

Connection

From Top And Bottom

Rated C

urrent (A)
