Cat6 RJ45 Keystone Jack with shutter

Product Overview

Description

Cat6 RJ45 Keystone Jack with shutter



Application:

1. Horizontal Distribution & backbone cabling

2. Australia faceplate



Techinical Details:

1. Electrical/Mechanical Characteristics:

- Insertion life : 750 mating cycles

-Plug  Retention Force: 89N

-Temperature: -40 °C~68°C

-Humidity: 10%~90% RH

-IDC Accept: 24-26 AWG Solid Wire

2. Approval:

-Wire scheme: T568A/B

-Category : CE &iso9001:2008& ROHS

-Fit for SMART Australia Faceplate

3.Material

-Housing : High Impact Flame Retardant Plastic ( Polycarbonate)

-Spring Wire: Phosphor bronze with 3u-50u gold-plated

-IDC Plastic : Polycarbonate( PC)

-IDC Contact: Phosphor Bronze with 100u nickle plated
