Product Overview

Description

Proxxon DB 250 mini manual woodwork lathe,woodworking copy lathe,mini cnc wood carving lathe





Parameter



Center spacing.  250mm,

Center height.  40mm.

Adjustable tailstock axis area. 25mm.

Supply.  220 - 240V, 100W, 50/60Hz.

Adjustable-Speed.  1,000 - 5,000rpm.

spindle bore.  10mm.

Tailstock area. 20mm.

Contain 6 tube chucks.  (2 - 3 - 4 - 6 - 8 - 10mm)

Central thimble,

Rotate thimble

Plane chuck







1. Stable tool holder can fix at any height With adjustable triangular compasses

2. contain 2 pcs of panels
3. 230V certificated motor (CE), noiseles, durable
4.  Thick aluminum working table











Description



1. Ball bearing spindle with taper, to assemble collet chuck, also with 10mm-diameter boring hole

2. Stable tool holder with adjustable triangular compassescan be fixed in any height

3. Contains the plane chuck

4. Speed 1,000 - 5,000rpm, high-speed motor can be controlled

5. The base used thickend aluminum

6. Tailstock working area is adjustable
