Without Brush Automatic Car Wash Plant for Long Time Service

Product Overview

Description

Without Brush Automatic Car Wash Plant for Long Time Service



Features and Advantages of automatic car wash plant:

1. It can be used to automatically wash cars, SUV, MPV, Minibus, etc. It automatically washes cars by     high-pressure spraying water. No damage to the car surface.

2. It has functions of automatic cleaning, waxing, foaming, drying.

    Easy to operate. One-touch operation for whole process.

3. It can be equiped with water cycle system.

4. Installation dimension: long 7 meter, wide 3.4meter, high 3meter.

5. Voltage: 380V or 440V or as your need.

6. Water consumption: 90 Liter/car   Power consumption: 0.5kwh



Technical data of eco automatic car wash plant:

Computer PLC	Taiwan Delta or SIEMENS	High pressure pump	Taiwan physical pump
The main control electric appliance	The French Schneider electric	The transmission system	Stepper motor
Detection system	Ultrasonic testing	Maintenance system	Automatic oiling
The operation interface	Color touch screen	Counting function	Yes
The L type jet rod	1 set	Fault self diagnosis function	Yes
Spray system	1 set	Effective washing width	2000mm
The lateral jet system	1 set	Effective washing height	2000mm
Cleaning free system	360°around	Washing speed	100 seconds/car
Remote control system	1 set	Wax system	Yes
Track length	7000mm	Machine height	3100mm
Power	15kw	Weight	1000kg













process: chassis washing-- car body washing with clear water-- Car detergent spraying-- fine washing -- car wax spraying--air drying





Delivery time: within 10 working days after got your payment

Payment Term: T/T or Western Union, L/C, ESCROW

Package: wooden case or as you need.
