unidirectional Carbon fiber fabric 200 gsm

Product Overview

Description

We can supply the unidirectional carbon fiber, carbon fiber, carbon fiber fabric .

fiber can be 3k,6k,12k
plain
width can be 10cm ~180cm
roll lentgh can be 100m

Please kinldy contact us for the detail specification and price quotation.

JINSOR Unidirection carbon fiber fabrics detail specifications

Code No (pictures) weave pattern Thickness (mm) width(cm) weight(g/m2) counts/inch fiber photos warp weft warp weft JSUD 120 plain 0.16 20~200 122 17 6 3K 34tex JSUD 150 plain 0.19 20~200 156 21.5 8 3K 34tex JSUD 200 plain 0.35 20~200 200 6 5 12K 11tex JSUD 250 plain 0.37 20~200 256 8 5 12K 11tex JSUD 300 plain 0.45 20~200 300 9 5 12K 11tex JSUD 400 plain 0.55 20~200 400 12 5 12K 11tex JSUD 500 plain 0.7 20~200 500 15.6 5 12K 11tex JSUD 600 plain 0.75 20~200 600 18.76 5 12K 11tex JSUD 800 plain 0.85 20~200 800 25 5 12K 11tex JSUD 1000 plain 1.05 20~200 1000 31.25 5 12K 11tex
