Single phase 220V 40A adjustable energy saving HF portable DIY CE approved IGBT DC air plasma cutter CUT 40
- Category: >>>
- Supplier: Keyue Welding Equipment Co. Ltd.
Share on (1978968755):
Product Overview
Description
Product description
Product feature
- Contact start without pilot arc
- Maximum cutting: 12mm
- Portable: 7kgs
- Material: mild steel, brass, stainless steel, copper, aluminum
| Model | CUT-40 |
| Input voltage(V) | 1PH AC220V±15% |
| Input power(KVA) | 5.5 |
| Input current (A) | 25 |
| Rated output | 98V/40A |
| Output current(A) | 20-40 |
| No-load voltage (V) | 243±5V |
| Duty Cycle% (40℃ 10min) | 40A 60% |
| 31A 100% | |
| Efficiency (%) | 70 |
| Protection grade | IP21 |
| Insulation grade | F |
| Method of arc start | contact |
| Net weight (KG) | 6.9 |
| Gross weight (KG) | 10 |
| Dimension of machine (mm) | 375*155*300 |
| Dimension of package (mm) | 440*230*390 |
Performance
Material | Sheet thickness (mm) | Arc start | Current range(A) | Model |
Carbon steel, stainless steel, low alloy steel | 0.3-16.0 | Contact | 20-40A | CUT-40 |
| 1.0-25.0 | Contact | 20-60A | CUT-60 | |
| 1.0-30.0 | Uncontact | 20-100A | CUT-100 | |
| 1.0-35.0 | Uncontact | 20-120A | CUT-120 | |
| 1.0-40.0 | Uncontact | 20-160A | CUT-160 | |
| 1.0-50.0 | Uncontact | 20-200A | CUT-200 | |
| Copper, Copper alloy, Aluminum, Aluminum-alloy | 0.3-8.0 | Contact | 20-40A | CUT-40 |
| 1.0-13.0 | Contact | 20-60A | CUT-60 | |
| 1.0-15.0 | Uncontact | 20-100A | CUT-100 | |
| 1.0-18.0 | Uncontact | 20-120A | CUT-120 | |
| 1.0-20.0 | Uncontact | 20-160A | CUT-160 | |
| 1.0-25.0 | Uncontact | 20-200A | CUT-200 |
