8mm high strength carbon elevator steel rope

Product Overview

Description

 8mm high strength carbon elevator steel rope



We mainly supply high quality elevator wire rope as per customers' requirements as below:
--- 6×19S+Fc, 6×19W+Fc
--- 6×29Fi+Fc, 6×36WS+Fc
--- 8×19S+Fc, 8×19W+Fc, 8×25Fi+Fc
--- 8×19S+IWR, 8×19W+IWR, 8×25Fi+IWR
--- 9×19S+IWR, 9×19W+IWR, 9×21Fi+ IWR, 9×19S+9×7+Fc, 9×19W+9×7+Fc, 9×21Fi+9×7+Fc



Frame	6×19S+Fc			6×19W+Fc
wire ropeNominal diameter mm	Reference weight kg/100m	Most breaking rally/kN
		Double strength/Mpa				Single-strength/Mpa
		1180/1770	1320/1620	1370/1770	1570/1770	1570	1620	1770
6	12.9	16.3	16.8	17.8	19.5	18.7	19.2	21.0
6.3	14.2	17.9	—	—	21.5	—	21.2	23.2
6.51)	15.2	19.1	19.7	20.9	22.9	21.9	22.6	24.7
81)	23.0	28.9	29.8	31.7	34.6	33.2	34.2	37.4
9	29.1	36.6	37.7	40.1	43.8	42.0	43.3	47.3
9.5	32.4	40.8	42.0	44.7	48.8	46.8	48.2	52.7
101)	35.9	45.2	46.5	49.5	54.1	51.8	53.5	58.4
12	51.7	65.1	67.0	71.3	77.9	74.6	77.0	84.1
12.7	57.9	72.9	75.0	79.8	87.3	83.6	86.2	94.2
131)	60.7	76.4	78.6	83.7	91.5	87.6	90.3	98.7
14	70.4	88.6	91.2	97.0	106	102	105	114
15	80.8	102	—	111	122	117	—	131
161)	91.9	116	119	127	139	133	137	150
17.5	110	138	—	—	166	—	—	179
18	116	146	151	160	175	168	173	189
191)	130	163	168	179	195	187	193	211
20	144	181	186	198	216	207	214	234
20.6	152	192	—	—	230	—	—	248
221)	174	219	225	240	262	251	259	283

Q: Manufacturer or Trader?
A: We are manufacturer in wire industry for more than 20 years.

Q: Producing Capacity?
A: The producing capacity totally is 9, 000 tons per month. The producing capacity of this product is 1,500 tons per month.

Q: Main Market?
A: Our main market is foreign customers. 80% of the products are for exporting. The main countries are Japan, South Korea, South Asian area, Europe, America, Canada, and South America etc.

Q: What information should I provide when inquiring?
A: The diameter before pvc coating; after pvc coating, the requirement of the core wire like zinc coating, tensile strength, packing, colour

Q: What is the MOQ?
A: For quality checking, we accept small quantity order like one coil. For normal cooperation, we prefer FCL container quantity to ensure the safety of goods in transportation.

Q: What is the payment term?
A: T/T; L/C; D/P etc

Q: Free sample available?
A: Yes. Free sample within 2kg is available

Q: Third Party Inspection available?
A: Yes, available. The charges are on the buyer.
