polyester geo mesh for road soil reinforcement material

Product Overview

Description

    polyester geo mesh for road soil reinforcement material





Introduction





technical specification



                                    Short fiber nonwoven geotextile technical data



c	Item	Value											Note
		100	150	200	250	300	350	400	450	500	600	800
1	Weight Variation(%)	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6
2	Thickness(mm)≥	0.9	1.3	1.7	2.1	2.4	2.7	3	3.3	3.6	4.1	5
3	Width Variation%	-0.5
4	Breaking Strength(   KN/m)≥	2.5	4.5	6.5	8	9.5	11	13	14	16	19	25	MD and TD
5	Elongation at break%	25-100
6	CBR Mullen Burst   Strength KN≥	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.2	4
7	Sieve Size O90(mm)	0.07-0.2
8	Vertical Permeability   Coefficient cm/s	K×(10-1-10-3)											K=1.0-9.9
9	Tearing Strength KN≥	0.08	0.12	0.2	0.2	0.2	0.3	0.3	0.4	0.4	0.5	0.6	MD and TD



                                    Filament spunbond needle punched geotextile



Number	Item	Value
		100	150	200	250	300	350	400	450	500	600	800
1	Weight Variation(%)	-6	-6	-6	-5	-5	-5	-5	-5	-4	-4	-4
2	Thickness(mm)≥	0.8	1.2	1.6	1.9	2.2	2.5	2.8	3.1	3.4	4.2	5.5
3	Width Variation%	-0.5
4	Breaking Strength(   KN/m)≥	4.5	7.5	10.5	12.5	15	17.5	20.5	23	25	30	40
5	Elongation at break%	40-80
6	CBR Mullen Burst   Strength KN≥	0.8	1.4	1.8	2.2	2.6	3	3.5	4	4.7	5.5	7
7	Sieve Size O90(mm)	0.07-0.2
8	Vertical Permeability   Coefficient cm/s	K×(10-1-10-3),K=1.0-9.9
9	Tearing Strength KN≥	0.14	0.2	0.28	0.35	0.4	0.49	0.56	0.6	0.7	0.8	1.1



















 1. How about the delivery time?

Lead time since receipt of 30% T/T deposit payment: 1 weeks.



2. What kind of payments does jenor support?

T/T are accepted.



3. What's are the MOQ?

We can according to your condition to set the MOQ.

And we can provide you samples for quality inspection.



4. Do you charge for the samples?

Accordeing to our company policy, the samples are freee, we only charge the freight fee.

And we will return the freight fee If you set the order .



5. Can you produce the product according to customers' requirements ?

Sure, we are professional manufacturer, OEM and ODM are both welcome.



6. Can you tell me your main customers?

That's our customers' privacy, we should protect their information.

At the same time, please rest assured that your information is also safe here.
