AOPU is one of most professional access control providers. As a High-tech company, We are focusing on access control devices’ development, production and selling, and provide complete solution.
12 years production experience brings a range of products to meet market demand: RS485 access controller, TCP/IP access controller, Bank inter-locking access controller, elevator access controller, locker access controller, Telecommunication station controller, embedded access controller, on line guard tour system.
Currently, we are doing OEM, ODM for dozens of companies, and hundreds of companies are selling AOPU products which are widely used in office, administrative organ, modern communities…
Our Services : 3 years warranty
Packaging & Shipping : DHL UPS FEDEX BY SEA
Product Description
Reader
8 pcs of Wiegand readers or 8 pcs 485 readers
Alarm output
1 (1-65535 sec)
Alarm input
1
Fire alarm output
1
Fire alarm input
1
Release button
4
Door sensor
4
Lock output
4
Parameter:
Card capacity
30000
Log records
60000
Alarm capacity
10000
Communication
RS485
Door open method
Card
Password
Card+PW
Double card
Fist card
Software
Fire alarm
Release button
Door timer
Anti pass back
YES
MAY
YES
Basic parameters:
Model No.
E04D.NET
Panel size
145mm*1022mm*26mm
Panel color
deep blue
Panel weight
about 250g
Box color
Black
Box weight
1.6KG
Temperature
<=60 degre
Enviroment humidity
10%-95% R.H
Voltage
DC12V
Working current
<=130ma
Rated power
<=1w
Power off protection
10 years
Access control board software features:
Support RS485 and TCP/IP access controller at the same time. All of access controller is using the same software management.
Support access control and lift access controller and locker access controller management at the same time.
Support 3 kinds of language, and customer can add their own language as their will.
Simple operation, finishing operation by single click, double click, or right click.
Real time monitoring like and kinds of alarm, card swiping.
Support color indicating, using different color to stand for different records.
Support full screen showing.
Access,Support Access and SQL server at the same time. The default is Access.
Three operation authorized: set up users for door, set up door for users, and set up permission teams.
Support automatic shift arrangement(only SQL available)
Support daily records, user can check the operation and management history record, easy to manage and system maintenance.
