new copper hydraulic fitting rotary joint rotating swivel mechanism

Product Overview

Description

new copper hydraulic fitting rotary joint rotating swivel mechanism







Parameters



Media	water/ hot water
Max pressure	2.5MPa
Max temperature	80°c /130°c
Max speed	2000R.P.M







Advantages

1. The material of copper has good effect on rust-proof.

2, Two high-precision bearings are used to support the entire shell for a good coaxality, which

enables to run stable at a hig spped for a long time.

3.Low friction torque, no anti-rotational devices required

4,Using SUS 304 spring which has good resistance of corrsion and rust-proof capability

5.Available in both different size of thread and flange connection

6.We provide one year guarantee and you can free to get some accssories if it is damaged within one year









ABOUT US

Hongchang JUFA gives you a wide range of choices in ROTARY JOINT for coolant, hydraulic service,steam, oil and water.

We are providing these rotary joints in stainless, cast iron and brass material in different size. These rotary joints is highly

appreiated in the industry for its unique feature such as reliability, superior quality and is very easy to use and maintain.







Structure

Parts	Material
Housing	Brass
Rotor	Stainless steel304
Spring	Stainless steel304
Gasket	Graphite Asbestos
Seal Ring	Carbon/ Graphite
Bearing	NSK Bearing
Head	Brass









new copper hydraulic fitting rotary joint rotating swivel mechanism











What is our shipping way and payment terms?



Shipping



1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;



2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;



3. Customers specifying freight forwarders or negotiable shipping methods!



4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.



Payment Terms



1. Payment: T/T, Western Union, ,PayPal; 30% deposits; 70% balance before delivery.



2. MOQ: 1pc















FAQ



Q1: What is the Warranty for the rotary joint?

A1: For the rotary joint, we have 1 year warranty. We replace the assemble for you for free.



Q2: What is the delivery time

A2: For the rotary joint, we have many size available in stock. Delivery time could be 3 to 7 days if normal size



Q3: Could you provide custom size product for us?

A3: We welcome custom size and can arrange the production according to your drawing or request.



Q4: What kind of media that your rotary joint can used for?

A4: We have different kinds of rotary joints for water, hot oil, steam and air.



Q5: What kind of seal you use for to guarantee the good sealing performance?

A5: We use graphite seal, mechanical seal and spherical seal with good sealing performance.



Q6: Can we only buy some assemble of the rotary joint?

A6: Yes, we can provide you with the seal, spring or other assemble.



Q7:Is there cheap shipping cost to import to our country?

A7: For small order,express will be best.And for bulk order,sea ship way is best but take much time. For urgent orders,we suggest via air to airport plus our ship partner send to your door.



Q8:Can we get support if we have our own market position?

A8: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.









Do you have Another kind of rotary joint?

Just click the below picture to get more information!!







Foshan Nanhai Hongchang Jefer Electromechanical Valve Co.,Ltd is a factory set up in 2006. We are specializing in researching, developing and manufacturing different kinds of rotary joints, flexible metal hose, rubber hose , bellow expansion joint and valve equipmentin China.







Our factory is covering over 10,000 square meters. Our R&D department consists of 3 engineers. Also, we have experienced QC personnel to check all our products strictly before packaging . All of our products meet the national standards and have pass ISO9001 certification. We obtain trust from customers by advanced technology, excellent quality and satisfactory service. Also, we specialized incustomized rotary jointstailored to meet your project requirements.







Our mission is: Offering high-quality goods, excellent service, and reasonable price to customers; Using our product, you will get more benefits!





















What is the application of our rotary joint?

Primary Industries:Chemical • printing • rubber • metals • textiles • plastics • food • paper •

machine tools • building materials • construction equipment
