Stainless Steel Sweet Snack Biscuit Making Machine For Food Industry

Product Overview

Description



Biscuit baking machine is used for baking biscuits, cookies and potato chips and crisp and  many more products, with four models as below:

Type	Length of oven	Heating zone	Output capacity
620	50M	3	500-630KG/H
800	60M	4	750-1000KG/H
1000	60M	4	880-1130KG/H
1200	60M	4	1000-1250KG/H













Heated by LPG(Liquefied Petroleum Gas), natural gas or electricity.

Pre-manufactured and insulated in 3-m-modules for fast and easy installation.

Burner flames heat up the burner chamber and the tubes in the heat exchanger.

Heated air transferred via tubes to the top and the bottom of the baking chamber.



Combustion gases removed by flue system without contacting the products.

Heat recovery unit for energy savings and reduction of CO2 emissions.

Burners controlled by temperature sensor to ensure constant and correct baking temperature.



Band driving and tensioning stations ensure smooth running of the bands.



PLC controlled and operation via touch screen.



Burner:weishaupt brand from Germany







Depending on the product, various types of oven bands are used:

Steel band for soft products and cookies baked directly on the band.

Wire mesh band for biscuits baked directly on the band.



Steel band

Unbaked Cookies



Baked cookies



Wire mesh band









 Wooden case packing.





Provide customers with complete biscuit production line, including whole factory project, system design, technological process, production line configuration, equipment modification plan and project implementation,etc.
