Air Cooler Fan Motor

Product Overview

Description

Air Cooler Fan Motor



Features:

1) IP22 enclosure;

2) Class F insulation;

3) Corrosion resistant;

4) High quality lamination steel giving very low iron losses;

5) High quality magnet wire;

6) Vacuum varnish impregnation for superior tropic proof insulation;

7) Industrial type service factors;

8) High temperature heavy duty ball bearings;

9) Rolled steel motor body;

10) Thermal overload protection;

11) Long life capacitors( On request);

Advantages:

1) Quiet operation;

2) Reliable in country, city or factory environments;

3) Low vibration;

4) Superior life;

5) Different kind of speed on request



Model	HP	kW	Voltage	Currenct(A)	Hz	Speed	Eff(%)	Power Factor	N.W(Kg)
HEVAC-VS380	0.5	0.37	220-240	3	50	1260	67.6	0.984	8
HEVAC-VS580	0.75	0.55	220-240	4	50	1300	68	0.973	8.8
HEVAC-VS780	1	0.75	220-240	5.1	50	1300	68.1	0.987	8.8
HEVAC-VS1100	1.5	1	220-240	6	50	1370	70	0.959	11.4
