Product Overview

Description

EN12975 certified 58*1800mm  solar heat panel price

NON-FREEZING SOLAR VACUUM TUBE COLLECTOR FOR SPLIT PRESSURE SOLAR HEATING SYSTEM.

heat pipe solar vacuum tube collector Features

1, ECO-friendly and energy saving collector

2, 12tubes-30Tubes heat pipes

3, Guarantee: 5 years for complete system, 15 years for vacuum tube

4, SOLAR KEYMARK EN12975 certified products.





Heat Pipe Solar Collector Vacuum Tube Specification:

Three-target Vacuum Tube Performance and Specification:

Tube structure

All-glass double deck co-axial structure

Glass material

High borosilicate 3.3 glass

Outer tube diameter and glass thickness

Ø58±0.7mm; Glass thickness 1.6±0.15mm

Inner tube diameter and glass thickness

Ø47±0.7mm; Glass thickness 1.6±0.15mm

Tube dimension

58*1800mm

Absorption
coating
property

Coating material

CU/SS-ALN(H)/SS-ALN(L)/ALN

Sediment method

Three Target magnetron sputtering plating

Absorptivity

α =0.92~0.96 (AM1.5)

Emission ratio

Emission: ε=0.04~0.06(80°C±5°C)

Vacuum degree

P≤5.0X10-3(PA)

Stagnation temperature

(temperature inside of empty evacuated tubes)

260~300 °C

Average heat loss

ULT 0.4~0.6 W/(m2 *°C)

Hail resistance

Ø25 mm

Pressure-endure

1MPa

Absorber area per tube

0.08M2



heat pipe solar vacuum tube collector Material

1. Manifold Channel: 1mm thickness Red copper
2. Manifold Outer: 2.0 mm thickness Aluminum Alloy
3. Tube Size: 58mm x 1.800mm
4. Insulation layer: 40-45mm thickness Rock Wool /Polyurethane foaming
5. Hail resistance: 25mm
6. Max pressure: 6 bar
7. Frame: 2.0mm thickness Aluminum Alloy

8. Connections: 1/2", 3/4", 1" male thread



heat pipe solar vacuum tube collector Package: Air bubble film wrapped and carton box
