Acecare Tech produces portable gas cylinders through advanced technology. Compared with conventional respirators, we use aluminium or aluminium composite cylinders instead of steel ones, with weight reduction of 40%-70%, so they are more preferable for people with breathing problems.
Gas cylinder introduction:
Gas cylinder liners are made of high quality 6061 aluminium alloy materials. The manufacturing procedure includes punching, drawing, heat treatment, CNC flow forming spinning, inner surface treatment, etc. The wall thickness is uniform with little difference. The shape of shoulder and base are produced with high precision and consistency.
1. 15-year lifetime warranty;
2. 5-year requalification period; 15-year life;
3. Smooth, high quality, easy-care exterior finish.
Carbon Fiber Composite Cylinder lined with Aluminium Alloy | ||||||||||||||
Standard | Part No. | Thread size | Water Capacity (liters) | Empty Weight (kg) | Diameter (mm) | Length (mm) | Working Pressure (Mpa) | |||||||
GB | CRPIII-55-0.35-30-T | M18*1.5 | 0.35 | 0.45 | 61 | 235 | 30 | |||||||
CRPIII-55-0.5-30-T | 0.50 | 0.65 | 61 | 295 | ||||||||||
CRPIII-79-1.1-30-T | 1.10 | 1.10 | 85.5 | 315 | ||||||||||
CRPIII-101-1.5-20-T | 1.50 | 1.0 | 108 | 207 | 20 | |||||||||
CRPIII-105-1.6-20-T | 1.60 | 1.20 | 112 | 268 | ||||||||||
CRPIII-88-2.0-30-T | 2.0 | 1.50 | 96 | 433 | 30 | |||||||||
CRPIII-120-2.17-30-T | 2.17 | 1.5 | 112 | 380 | ||||||||||
CRP-III-120-2.4-20-T | 2.40 | 1.70 | 128 | 307 | 20 | |||||||||
CRPIII-120-2.5-20-T | 2.50 | 1.80 | 128 | 312 | ||||||||||
CRPIII-125-2.7-20-T | 2.70 | 1.90 | 133 | 308 | ||||||||||
CRPIII-125-4.7-30-T | 4.70 | 3.0 | 137 | 492 | 30 | |||||||||
CRPIII-145-6.8-30-T | 6.80 | 4.10 | 157 | 528 | ||||||||||
CRPIII-161-9.0-30-T | 9.0 | 5.20 | 174 | 560 | ||||||||||
CRPIII-192-12-30-T | 12.0 | 6.80 | 208 | 575 | ||||||||||
CRPIII-220-20-30-T | 20.0 | 12.0 | 222 | 770 | ||||||||||
CE | CRPIII-105-3.0-30-T | M18*1.5 | 3.0 | 2.10 | 114 | 446 | 30 | |||||||
CRPIII-144-6.8-30-T | 6.80 | 3.90 | 157 | 530 | 30 | |||||||||
CRPIII-162-9.0-30-T | 9.0 | 5.30 | 175 | 560 | 30 | |||||||||
DOT | TC 6.8L-30MPA | ISO M18*1.5 | 6.8 | 3.90 | 157 | / | 30 | |||||||
TC 4.7L-31MPA | 0.875-14UNF-2B | 4.7 | 2.90 | 140.4 | 31 | |||||||||
TC 6.8L-31MPA | 0.875-14UNF-2B | 6.8 | 3.90 | 172.5 | ||||||||||
TC 8.5L-15MPA | 0.750-16UNF-2B | 8.5 | 3.10 | 166.8 | 15 | |||||||||
TC 9.0L-31MPA | 0.875-14UNF-2B | 9.0 | 4.90 | 174.3 | 31 | |||||||||



Shenyang Acecare Technology Co., Ltd. is a professional import and export company with a branch office located in the United States. Our primary focus lies in the field of high-pressure gas cylinders, gas cylinder components, gas cylinder-related equipment, and the management of large-scale production projects.
Since our inception in 2010, we have achieved significant growth.Over the course of nearly 13 years, Acecare has forged
partnerships with industry-leading factories worldwide. This collaboration encompasses various aspects, including product development, sales channels, brand services, and the nurturing of a talented team.
Our products have reached more than 150 countries, including the North America, Europe, South America, Middle East, Oceania, Africa, we are experienced in transportation and will provide our customers with the best possible transportation solutions!
Acecare's mission revolves around delivering products of exceptional quality at reasonable prices, aligning with the diverse needs
of our esteemed customers. We have consistently upheld the principle of prioritizing our customers' satisfaction, and we eagerly
anticipate establishing cooperative relationships with friends and partners from all corners of the globe. Together, we can foster
mutual development for the greater good.





Payment term:T/T, Western Union and PayPal are acceptable. The best way is direct online payment. If you want other payment, please let us know when you order.
Trade term: EXW or FOB or CFR or CIF or CPT or CIP
Packing detail:Wooden box, Ply-wood box, Carton box, Pallet
Delivery time:It depends on the purchasing quantity and the stock condition, if the products are available in the warehouse, we can arrange the delivery very soon, or a few days after receiving the deposit.
Min. order:
If the ordered products are in stock. No MOQ limited.
if not,ordered quantity can be discussed with us.
