Aluminum Welding Wire Flux Cored Aluminum Ring for Copper and Aluminum welding

Product Overview

Description

ALUMINUM WELDING WIRES.
All the surfaces of welding material are smooth and clean.The welding wires are labeled with production number and date and source materials are kept for investigation.

TIG
LENGTH1m

SPECIFICATIONφ1.6   2.0     2.5    3.0     4.0     5.0    6.0

WEIGHT     10Kg/box

MIG
SPECIFICATIONφ0.8   0.9 1.0   1.2    1.6    2.0



Ring and Flux Cored Aluminum Welding Ring Available

WEIGHT    7Kg/box   6Kg/box     2Kg/box      0.5Kg/box

AWS Code	Chemical composition(%)
	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti
ER1060	0.25	0.35	0.05	0.03	0.03	----	0.05	0.03
ER1100	0.95	0.95	0.05-0.20	0.05	----	----	0.10	----
ER4043	4.5-6.0	0.80	0.30	0.05	0.05	----	0.10	0.20
ER4047	11.0-13.0	0.80	0.30	0.15	0.10	----	0.20	----
ER5356	0.25	0.40	0.10	0.05-0.20	4.5-5.5	0.05-0.20	0.10	0.06-0.20
ER5183	0.40	0.40	0.10	0.5-1.0	4.3-5.2	0.05-0.25	0.25	0.15
ER5556	0.1	0.3	0.05	0.55-8.0	4.7-5.2	0.05-0.10	0.09	0.05-0.10



As a manufacturer and exporter with more than 10 years exporting experience, we know which products can meet different markets requirement. We are confidence for our quality and competitive price.
