10 А 250 В переменного тока, Плунжер, ограничитель хода CLS101

10 А 250 В переменного тока, Плунжер, ограничитель хода CLS101

Category: Limit Switches >>>
Supplier: Zhejiang,Xurui,Electronic,Co.,Ltd.

Price:

Price in USD:Details

Quantity:

Product Overview

Description

10A 250VAC push button plunger Travel Limit Switch CLS101

Features:

Economic plastic outer shell,strong structure and high mechanical strength.

Preventing oil and water.

Double way switch, double spring inner switch.

Variety of levers.

Widely used in Mechanical equipment,automatic machine,and instrument,electro motion tool etc.

Technical Specifications:

Item	Data
Rating load	10 (4) A /250VAC, 6 (2) A 380VAC
Operation speed	5mm-0.5m/s
Operation frequency	Mechanical 120times/min
Operation frequency	Electrical 30 times/min
Contact resistance	≤25mΩ initial value
Insulation resistance	≥100MΩ DC500V
Withration voltage	Non-connection wire 1000VAC
Withration voltage	Every terminal 1500VAC
Operating life	Electrical 100,000 above
Operating life	Mechanical 1000,000 above
Protection degree	IP65
Operating temperature	-10°C-70°C
Operating humidity	≤85%

Contact Form & Mounting Hole Dimensions:

Product Structure:

Outshape and Dimension Drawings:

9101 dimension

XZ9 Limit Switch Full Modes As Below:
