Thermostatic Steam Trap (Balanced Pressure Type)

Thermostatic Steam Trap (Balanced Pressure Type):

Thermostatic steam trap with capsule regulator. Corrosion-resistant thermostatic capsule unaffected by waterhammer. Integral Y-type strainer and non-return valve. Asbestos-free cover gasket (graphite/CrNi). Installation in any position. The traps with standard capsule 5N1 discharge the condensate with virtually no banking-up, the traps with special capsule 5U1 with an subcooling of approx.

Materials:  Body (Cast Steel, Carbon Steel & Stainless Steel), Cover (Carbon Steel & Stainless Steel),  Internal Parts (Stainless Steel)

Dimensions: DN 15 - 50

Features and benefits:

• Very low subcooling
• Perfect air venting
• Quick response
• Pressure ratings up to PN 40
• Stainless steel Body for aggressive or sensitive surrounding
• Stainless steel Body for aggressive or sensitive surrounding
