Stranding Machine copper wire twister copper wire bunching machine
Stranding Machine copper wire twister copper wire bunching machine

Stranding Machine copper wire twister copper wire bunching machine

Share on (208547372):


Price:RUB 3,052,912.00 - RUB 4,579,368.00

Quantity:


Product Overview

Description


Double twist technical data
Machine type
HT- 300P
HT- 400P
HT- 500P
HT-650P
Main usage
Multi-copper wires intertwist
Stranding sectional area(mm2)
0.035 -1.45
0.035-1.5
0.05-2.5
0.18-9
Dia. Of single copper wire(mm)
φ0.05-φ0.28
φ0.08-φ0.45
φ0.1-φ0.68
φ0.38-φ1.0
Distance of intertwist
2.2-17.9 (1.2mm-28mm special)
4.08-31.5 (1.67mm-31.5mm special)
5.6-57.99 (or as customer`s request)
12.6-96.8mm
Electric motor
Tri-phase 4kw frequencey conversion speed-control
Tri-phase 5kw frequencey conversion speed-control
Tri-phase 5.5kw frequencey conversion speed-control
Tri-phase 7.5kw frequencey conversion speed-control
The Max. rotational speed of main axis
4000 r/min
3000 r/min
3000r/min
2000 r/min
Wire spooling tension structure
256 Magnetic clutch automatic adjustment

The size of bobbins
Outer dia. 300X total length 180mm
φ400mm
φ500mm
φ500mm
The largest capacity of bobbins
60KG


150KG
250KG
400KG
bobbin loading and unloading organization
Hand-movement-hydraulic pressure
bobbins Up and down by motor-driven

traverse
Polished rod-axletree style device of drop-out line, distance of drop-out line, drop-out line changeable
Polished rod-axletree style device of drop-out line, distance of drop-out line, drop-out line changeable
The numeration of intertwist wire length
Digital display, length-enactment auto-stop
wire broken detective
Stop machine by stop the inner and outer wire
The height of main axis from groud
635mm
685mm
700mm
850mm
Machine external dimensions
2150 X 1400 X 1200
2400 X 1100 X 1250
2850 X 1500 X1660
2850 X 1500 X1660
Net weight
950KG
1500KG
2800KG
3500KG

Machining Strength

machining equipments EN.jpg



Warranty

12 months counted from the date of signing the Certificate of Acceptance. But if due to the Buyer's reason, the commissioning and acceptance of the line is delayed, the guarantee period of quality shall be no more than 18 months from the arrival date of equipment at the destination port.
