Angular measurement of the arm, dam, construction, bridge
Aligning control, bending control
Initial position control, Grapher for tilt attitude
Technical data
Parameter
Value
Unit
Remarks
Measuring range
+/-30
degree
Two-axis
Resolution
0.005
degree
Accuracy
0.05
degree
@25 °c
Zero Temperature drift
+/-0.5
degree
Set 25°C as basic point, in the range of -40-+85°C
Response time
1
second
Operating voltage
9-24
V(dc)
Recommend 24V
Operating current
<60
mA
Operating temperature
-40-+85
°c
Storage temperature
-45-+125
Our service
1. Experienced staff answer all your questions in fluent English.
2. Customized design is available. OEM is welcomed.
3. The exclusive and unique solution can be provided to our customer by our well-trained and professional engineers
Company and product information related
We are the manufacture of tilt sensor in shanghai china. Our sensor is based on MEMS technology and the core chip is from VTI. As a professional manufacturer of tilt sensor in China, we can provide the following service for you:
