With perc. as degreasing agent, GXSQ and GXZQ series fully-auto dry cleaning machines are ideal equipment which incorporate the functions of washing, extracting, drying, solvent recovering and distillation.
It is suitable for hotel, laundry , factory, troop, hostel to wash various fabrics made of cotton, wool, chemical fibre, blanket, fur, down, etc.
Main Features:
1.After being dried cleaning, the garments will not be damaged, but clean, well-pressed, soft, non-shrinking, non-folding, non-decolorizing and antiborer.
2.Controlled by computer (except GXSB-6), it has the advantages of automatic adding agent, filtering, draining, extracting, drying.
3.The filter system may keep the solvent clean to ensure washing quality.
4.The drum and other key parts are made of stainless steel. The pneumatic valves are more stable and reliable.



Specification

Model



GXZQ-8



GXZQ-12

GXZQ-22F



Rated capacity(dry) kg



8



12

22



Rrum diameter×length



650×450



810×435

940×600



Washing&extracting motor        kw



0.4/1.5



0.55/1.8

3



Motor of filter  kw



0.55



0.55

0.55



Motor of liquid pump        kw



0.75



0.75

0.75



Motor of fan  kw



0.75



1.1

1.5



Distilling power

(electric heating)      kw



5.4



6

13.5



Drying power

(electric heating)      kw



7.2



9

13.8



Washing/extracting speed       rpm



40/400



40/400

40/400



Work pressure of steam       mpa



0.4-0.5



0.4-0.5

0.4-0.5



Cooling water pressure(<25)



0.2-0.3



0.2-0.3

0.2-0.3



Compressed air pressure     mpa



0. 5- 0.7



0. 5- 0.7

0. 5- 0.7



Detergent





Dimension (L×W×H)   mm



1595×1000×1880



1650×1160×2120

1600×1970×2320

Machine weight



950/1000



1040/1100

2300
