cost of cement plant equipment

Product Overview

Description

 cost of cement plant equipment



High efficient & low consumption cement plant equipment

A. Summary of cement plant equipment:

1. The production method is dry process. A rotary kiln(φ3.5×54m) production line with five-stage cyclone pre-heater and decomposition furnace will be adopted.

2. Production scale and capacity

The production capacity is 1500t/d for clinker, while 500,000t/a for Portland cement when mixed with gypsum.

3. Cement types

The technology and equipment adopted can produce 32.5MP and 42.5MP types of cement in accordance with Chinese Standard GB175-1999. They can be adjusted according to market demand.

4. Raw materials properties chemical composition



Name	L.O.I	SiO2	Al2O3	Fe2O3	CaO	Mgo	K2O	Na2O	SO3	Cl-	Water content
Limestone	39.27	7.17	2.93	1.25	46.94	1.03	0.13	0.23		0.009	0.45
Shale	21.89	36.14	10.39	3.27	22.03	0.8	0.99	0.33		0.015	0.46
Silica	0.10	95.5	1.00	0.20	0.90	0.50
Gypsum		1.40	0.60	0.20	30.52	0.05	0.10	0.10	47.10		18.70
iron	11.5	30.56	22.12	26.91	1.12

5. Fuel

The technical property of mazut:Min. value is ≥9000 kcal/kg(37620kJ/kg)



New five-stage cyclone pre-heater system, high efficiency air girder grate cooler, multi-passage pulverized coal burner, heat temperature fan, electrical dust collector, as well as chain-board elevator, chain conveyor adopted in this cement plant equipment can ensure that the technology is advanced compared to other production lines with the same scale.



6. Main scope of the cement plant equipment:

a. Mechanical Equipment of the cement plant :

1.Limestone crushing & conveying

2..Clay crushing & conveying

3.Clay & iron powder pre-homogenization pile

4.Limestone pre-homogenization pile

5.Raw material dosing station

6.Raw material grinding & exhaust gas treatment

7.Raw meal homogenization silo & feeding kiln

8.kiln outlet

9.Rotary kiln & triple air duct

10.Kiln inlet & clinker conveying

11.Raw coal crushing & conveying

12.Raw coal pre-homogenization pile & conveying

13.Coal powder preparation & conveying

14.Clinker, gypsum storage & dosing & conveying

15.Gypsum crushing & conveying

16.Cement grinding & conveying

17.Cement storage & bulk loading

18.Cement packing & conveying

19.Chemical laboratory equipment

b.Electrical & automation of cement plant

7. The main equipment for cement making machinery:

a. rotary calcining kiln     b. vertical roller mill        c. air swept coal mill

d. cement ball mill         e. crusher                 f. Conveyor

8. The packing of our cement making equipment:



B. Key benefits of our services for cement plant equipment

Single source for complete engineering, procurement and construction know-how

  Full life-cycle support, from initial raw material investigation to final commissioning

  Full integration and interconnection of products, including all auxiliary  equipment

Shortest time to full production

Single source for all service requirements

Expertise and know-how to limit project risk

Reliable, energy-efficient technologies
