Product Overview

Description

light prefab warehouse steel structure drawing

Steel warehouse has the advantage of being light weight,high strength,easy installation and maintenance, as well as low cost.

Steel warehouse is a new type of building structure system, which is formed by the main steel framework of H-section, Z-section, C-section and other steel components linked up.





Size	length X Width X Eave height, roof Slope
Type	single slope, double slope, muti-slope;
	single span,double-span ,multi-span;
	single floor, double floors
Column and beam	hot rolled or weld H section steel, grade Q345(S355JR)
Bracing	X or V or other type bracing made from angle , round pipe
Purlin	C or Z section size of C100~C320,Z160~Z300
Roof and wall	single colorful corrugated steel sheet;
	sandwich panel with insulation of EPS, ROCK WOOL or PU
Accessories	semi-transparent skylight belts, ventilators, down pipe, out gutter etc.
Surface	frame steel:twice anti-corrosive primer and one finish paint;
	secondary steel:hot galvanized
Package and loading	nude cargo loaded into 40'HQ







Wide span: single span or multiple spans

Low cost: unit price range from USD30/m2 to USD40/m2 as per your request Fast construction and easy installation Long lifespan: about 20~ 50 years for the structure Others: environmental protection, stable structure, earthquake resistance,

water proofing and energy conservation.

1.Attractive design---beautiful and elegant looks, using the color corrugated steel sheet or sandwich panel, the insulation material is EPS, rock wool or PU.



2.Easy assemble and dismantle---can be rebuilt for dozens of time with bolts and screws.



3.Firm structure----steel frame structure and sandwich panels



4.Durable----the steel frame parts are all processed with anti-corrosion coated and can be used for as long as 30 years in good maintance.



5.Low cost by integrating & manufacturing & service processes.



6.With reliable quality and efficient service from designing, manufacturing to installation



7.Sizes and design are according to your requirements





1. Stable structure: Safe and reliable light steel structure system.



2. Attractive looks: Colorful corrugated galvanized steel sheet or sandwich panel as wall & roof panel.



3. Easy & quick to install: Repeated use, simple tools for installation.



4. Economical: Compared with concrete buildings, it costs much less.



5. Long life span: The steel structure frame coated with anti-corrosive painting could stand more than 20 years in good maintenance.



6. Environmental friendly: Professional design, easy installation, recyclable use.



7. Extensive application: Construction site, office building, industrial workshop,warehouse,exhibition center,etc.



Quality control



We perfoms strict quality control system during the production process. Groove check,hole check,Pitch inspection,Preheat temperature checking,steel component's dimension,inspection, paint film thickness check,etc.And pre-loading quality supervision is acceptable.









(1) Simple Steel Structure Warehouse/Workshop
Main structure	Single span: L -shorter than 18m, H -lower than 6m
Containment system	Roof			Color galvanized steel sheet
	Wall			Color galvanized steel sheet
	Door			Roll up or sliding door
	Window			Sliding or side hung window
Usage	Warehouse, workshop
Suitable zone	Africa, Middle-East, South America(no snow, wind load below 0.4kn/m2)
(2) Standard Steel Structure Warehouse/Workshop
Main structure		Single span: L -shorter than 24m, H -lower than 8m
Containment system		Roof		50mm thk of glass wool sandwich panel
		Wall		Color steel sheet or 50mm thk sandwich panel
		Door		Roll up or sliding door
		Window		Sliding or side hung window
Usage		Warehouse, workshop, shopping mall, exhibition hall
Suitable zone		Snow load below 0.5kn/m2,wind load below 0.5kn/m2
(3) Coastal (high wind speed) Steel Structure Warehouse/Workshop
Main structure		Single span: L -shorter than 18m, H -lower than 6m
Containment system		Roof		50mm thk of glass wool sandwich panel
		Wall		Color steel sheet or 50mm thk sandwich panel
		Door		Roll up or sliding door
		Window		Sliding or side hung window
Usage		Warehouse, workshop, shopping mall, exhibition hall
Suitable zone		Coastal areas (snow load below 0.7kn/m2, wind load below 1.2kn/m2)
(4) Cold Region (heavy snow) Steel Structure Warehouse/Workshop
Main structure		Single span: L -shorter than 18m, H -lower than 6m
Containment system		Roof	EPS/rock wool/PU sandwich panel
		Wall	EPS/rock wool/PU sandwich panel
		Door	PU foam rolling door
		Window	Sliding or side hung window
Usage		Warehouse, workshop, shopping mall, exhibition hall, super market
Suitable zone		Cold regions such as Norway,Russian,North Canada,Finland,Iceland, Greenland, etc. (snow load below 3kn/m2, wind load below 1kn/m2)
(5) Steel Structure Warehouse/Workshop with Crane (5T, 10T, 20T)
Main structure		Single span: L -shorter than 20m, H -lower than 10m
Containment system		Roof			50mm thk of glass wool sandwich panel
		Wall			Color steel sheet or sandwich panel
		Door			Roll up or sliding door
		Window			Sliding or side hung window
Usage		Warehouse, workshop
Suitable zone		Snow load below 0.5kn/m2, wind load below 0.5kn/m2



We can quote if you can offer the following information



If you need we design for you, pls supply us the following parameter together with detailed size:



1.Data for design

*live load on roof(KN/M2), live load on second floor(KN/M2) if have

*wind speed(KM/H) or wind load(Kn/M2)

*snow load (Kn/M2) if have

*earthquake grade if have

*crane (if have): crane span, crane type, crane quantity, crane lift height, max lift capacity,

max wheel pressure and min wheel pressure.



2.Type of the building

*dimension: width,length,eave height and roof slope

*single slope or double slope

*single span,double span or multi span

*single floor,double floor or multi floor



3.Materials and accessories

*Roof and wall pane: sandwich panel or corrugated steel sheet

*Windows and doors: quantity,size,type and location

*Skylight band, ventilator and any other accessories if needed.



We will furnish you the detailed construction drawing and the construction manual which could

help you to erect and install the building step by step. We also could send the engineer to your

local to help you if needed.





Please contact us for a competitive price and we are committed to provide the best possible services and solutions for your project.
