ENC Series Coordinate Measuring Machine
- Category: >>>
- Supplier: Suzhou Easson Optoelectronics Co. Ltd.
Share on (256962618):
Product Overview
Description
ENC Series Automatic Coordinate Measuring Machine
| Model | ENC-565 | ENC-585 | ENC-8106 | ENC-8156 | |
| X,Y,Z traveral (mm) | 500x600x500 | 500x800x500 | 800x1000x600 | 800x1500x600 | |
| Useable table size (mm) | 1100x800 | 1300x800 | 1710x1030 | 2210x1030 | |
| Weight (kg) | 1200 | 1400 | 1800 | 2260 | |
| Worktable max load (kg) | 500 | 500 | 1000 | 1000 | |
| Scale resolution | 0.5 μm (0.1μm for option) | ||||
| Probe uncertainty (MPEE) um | TP20 | 2.6 | 2.8 | ||
| TP200 | 2.2 | 2.4 | |||
| Space uncertainty (MPEP) um | TP20 | 2.4+L/300 | 2.6+L/300 | ||
| TP200 | 2.2+L/300 | 2.4+L/300 | |||
| Joystick mode Vmax | 0-20mm/s (slow speed mode), 0-100mm/s (normal mode) | ||||
| CNC Mode Vmax | Single axis 300mm/s, Space 520 mm/s | ||||
| CNC Mode Amax | Single axis 900mm/s2, Space 1500 mm/s2 | ||||
| Working temperature | 15- 30°C | ||||
| Air supply | Pressure 4-10 bar, 160NI/min | ||||
| Model | ENC-10128 | ENC-10158 | ENC-10208 | |
| X,Y,Z traveral (mm) | 1000x1200x800 | 1000x1500x800 | 1000x2000x800 | |
| Useable table size (mm) | 2000x1250 | 2300x1250 | 2800x1250 | |
| Weight (kg) | 2800 | 3500 | 4200 | |
| Worktable max load (kg) | 1500 | 1500 | 1800 | |
| Scale resolution | 0.5 μm (0.1μm for option) | |||
| Probe uncertainty (MPEE) um | TP20 | 3.2 | ||
| TP200 | 2.8 | |||
| Space uncertainty (MPEP) um | TP20 | 3.0+L/300 | ||
| TP200 | 2.8+L/300 | |||
| Joystick mode Vmax | 0-20mm/s (slow speed mode), 0-100mm/s (normal mode) | |||
| CNC Mode Vmax | Single axis 300mm/s, Space 520 mm/s | |||
| CNC Mode Amax | Single axis 900mm/s2, Space 1500 mm/s2 | |||
| Working temperature | 15- 30°C | |||
| Air supply | Pressure 4-10 bar, 160NI/min | |||
| Model | ENC-121510 | ENC-122010 | ENC-122510 | ENC-123010 | |
| X,Y,Z traveral (mm) | 1200x1500x1000 | 1200x2000x1000 | 1200x2500x1000 | 2000x3000x1000 | |
| Useable table size (mm) | 2350x1500 | 2850x1500 | 3350x1500 | 3850x1500 | |
| Weight (kg) | 4500 | 5000 | 6000 | 7000 | |
| Worktable max load (kg) | 2000 | 2000 | 2500 | 2500 | |
| Scale resolution | 0.5 μm (0.1μm for option) | ||||
| Probe uncertainty (MPEE) um | TP20 | 3.6 | |||
| TP200 | 3.2 | ||||
| Space uncertainty (MPEP) um | TP20 | 3.4+L/300 | |||
| TP200 | 3.2+L/300 | ||||
| Joystick mode Vmax | 0-20mm/s (slow speed mode), 0-100mm/s (normal mode) | ||||
| CNC Mode Vmax | Single axis 300mm/s, Space 520 mm/s | ||||
| CNC Mode Amax | Single axis 900mm/s2, Space 1500 mm/s2 | ||||
| Working temperature | 15- 30°C | ||||
| Air supply | Pressure 4-10 bar, 160NI/min | ||||
