operation anesthesia kit Anesthesia Workstation with ventilator
- Category: >>>
- Supplier: Beijing Aeonmed Co. Ltd.
Share on (282666057):
Product Overview
Description
Technical Specification
Physical & Environmental Specification
. Dimensions (WxHxD): 930x1354x620mm
. Weight: 120kg
. Storage temperature: -10~+55
. Working temperature: +10~+40
. Storage humidity:≤93%
Electrical Specification
. Main power: 100-240VA C, 50-60Hz
. Battery: 24VDC, minimum90min
. Power consumption:≤70W
Pneumatic Specification
. O2: 0-1L/min; 1-10l/min
. N2O:0-1L/min; 1-10L/min
. Gas system: O2deficiency alarm
Hypoxic guard system
O2flush: 35-75L/min
. Working mode: Closed, Semi-closed, Semi-open
. Driven mode: Pneumatically driven and electronically controlled
. Operating mode: Man. / Vent.
. Safety valve:≤8kpa
Ventilator Specification
. Patient type: Adult, pediatric
. Ventilation modes: IPPV, PCV, SIMV(flow-trigger) , Manual
. Setting: Touch key & navigator wheel knob
. Tidal volume: 0-1500ml
. Ventilation frequency: 4-100bmp
. I:E ratio: 2:1-1:8
. Pressure control: 5-70cmH2O
. Ppeep: 0-20cmH2O
. Inspiratory plateau: 0-60%Ti
. Trigger sensitivity: 2-30L/min
. High pressure: 21-80cmH2O
. Low pressure: 0-20cmH2O
. Monitoring Display: 10.4TFT color screen
Pressure: Paw, Ppeak, Pplat, Pmean
Volume: MV, Vt
Breath rate
Gas: FiO2
Compliance
Graph display: P-T, F-T, V-T waveforms & P-V, F-V loops
. Alarm: Pressure: Paw, high/low limit
Volumes: MV high/low limit
High limit of breath rate
Gas: FiO2 high/low limit
Low O2 supply pressure
Airway malfunction
Power failure
Vaporizer
. Support 2 vaporizer (Selectatec compatible)
.Agent type: Halothane, Enflurane, Isoflurane, Sevoflulrane available
Product Description
Company Information
BEIJING AEONMED CO., LTD. is a leading OR and ICU equipment manufacturer and medical system solutions supplier. There are 6 business lines of OR and ICU including, anesthesia machines, ventilator, operation table, surgical light, medical pumps and ceiling pendants. And five Medical System Solutions which including Laminar Flow,Environment and Equipment Configuration ,Centralized Gas Supply ,Process Quality Control and Information Integration.
In 2008, one anesthesia machine designed and made by Aeonmed was successfully launched in the US market which made a breaking through for the Chinese anesthesia manufacturers. So far Aeonmed's products have been sold to more than 120 areas and countries, and 61 products have received the CE certificate. We are proud that one of our emergency ventilator, Shangrila 510, was selected among almost the most famous brand around world as standby support for emergency use on every event spot, the total number was 175 units. In June 2013, Aeonmed’s intensive care ventilator gains the access to the US market. It is milestone of ventilator business developing in China.
Independent innovation built Aeonmed's competitive ability. To date, over 800 patents have been approved or applied, including over 500 invention patents. Aeonmed maintaining a substantial annual increase of more than 100 patents.
"Reliable Quality, Thoughtful Service” is Aeonmed’s commitment to customers”, and “Guard life sincerely" is the sacred mission of Aeonmed.
Facing the future, Aeonmed people are working enthusiastically towards company's vision – to be "the Operating Expert of OR & ICU".
