  • 4 х канальный GSM FWT/ GSM FCT беспроводной терминал один год гарантии
4 х канальный GSM FWT/ GSM FCT беспроводной терминал один год гарантии
4-х канальный GSM FWT/ GSM FCT беспроводной терминал один год гарантии

4 х канальный GSM FWT/ GSM FCT беспроводной терминал один год гарантии

Share on (288265130):


Price:

Quantity:


Product Overview

Description


Name: 4SIM(Cards) GSM Fixed Wireless Terminal

Model:VIN204

Main Features:
  •  Dialing tone
  •  DTMF Dialing
  •  FSK/DTMF Caller ID.
  •  Bell signal
  •  Polarity reversal Signal supported
  •  The RJ-11 socket which connects the phone or the payphone
  •  Antenna socket (FME)
  •  IP usage switch
  •  Working state indicator
  •  Signal Strength indicator

Functions:
  • Suitable for using G-SIM (Cards) in the GSM network: GSM 900/1800Mhz, or
        GSM850/900/1800/1900Mhz(optional)
  • Standard RJ11 phone socket interface
  • Making&answering calls after connecting to telephone set
  • Can be compatiable to connect with telephone set,PBX(for office use), VoIP Gateways(for  call termination),and etc.
  • Provide reversal polarity signal for billing meter
  • Caller ID With DTMF/FSK (FSK is optional)
  • Built-in PIN code protection featured with locking device/SIM card/network
  • Support the functions of redialing and hands-free
  • Hide CID for phone number of calling out
  • Supply two set extensions to connect
  • Can set local code,IP access code and special number,limiting to dial national long distance call,mobile phone call,local call, and also can set using IP phone call.
  • Voice adjustment of calling in and out,multi-level volume to be chosen
  • Featured with signal intensity indicator,working status indicator,breakdown indicatior,and etc.
  • Can proceed with setting up and modification of parameters through the phone set

Technical Data:

1)Antenna interface standard:GSM 900/1800MHZ.
 GSM850/900/1800/1900MHZ(option)
2). SIM Card:Support 3V G-SIM card.
3). Phone interfaceSupply RJ-11 Phone Interface
On-hook voltage:45V
Off-hook current30mA/41mA
Dialing tone Frequency450Hz
Ring voltage: 75V,25HZ,1second ring,4seconds silence
4). Antenna interface
Antenna Gain 1.5DB
Sensitivity -104DBM
Antenna Transmission power≤3W
5). Adapter interface
INPUTAC 110v/220v
OUTPUT+12V/6000MA
 6). Serial communication interfaceRS-232 full serial interface mode (with assigned date transport line)

Working environment:
Operation temperature-10 ~ 60
Storage temperature-20 ~ 70
Operation humidity45% 95%
Atmosphere pressure86 106Kpa
Environment noise:60DB
