Accurate vehicle gps tracker with Dual sim card, motion shaking sesonr tk103B gps car tracker

Product Overview

Description

gps car tracker



General
Based on GSM/GPRS and GPS, you can locate and monitor any remote targets by SMS or GPRS.

Feature
1.Get the targets latitude and longitude by SMS or GPRS, and check position on google earth/maps.
2.Support GPRS data transmission.
3.Support sending commands by computer
4.Remote sending commands by GPRS server and SMS
5.Support two GSM Sim cards, the unit works with the other card automatically when one card has no GSM signal or no phone charge.
6.Support storing data in SD card, the GPS data will be stored into the SD card automatically when there's no GPRS signal.
7.Auto Report position.
8.Send the last location if the target enters into the blind area.
9.Add or change Username and Password and Authorized number.
10.Remote Monitoring and SOS function,and Two-way communication.
11.Send a Geofence alert to the user when it breaches the restricted area.
12.Send a movement alert to the user when it begins to move.
13.Send an overspeed alert to the user when it moves exceed of the restricted speed.
14.Send a low battery alert to the user if the battery is low.
15.Send an alert of theft to the user automatically if the power be cut off or the vehicle be startup illegally.
16.Send SMS to the unit to cut off the vehicle engine and circuit when someone startup the vehicle illegally in anywhere and anytime.



Fortifying Mode
1 Engine Started Alert
2 Movement Alert
3 Power Cutoff Alert
4 Application in the Car Alarm System
5 Checking the Working Status





Tracking Mode

1  Initialization
2  Change the Password
3  Authorization
4  Auto Track
5  Geo-fence
6  Movement Alert
7  Overspeed Alert
8  IMEI Checking
9  SOS
10  Low Battery Alert
11  SMS Center
12  GSM ID
13  Motion Sensor
14  SD Card Function
15  Dual SIM card A-B Transformation
16  Monitoring Mode
17  Remote Oil&Electricity Cut-off Function
18  GPRS Setting
19  Cautions
20  Faults & Solutions





Applications
Manage vehicle rental or outside equipment,etc.
Fleet management.





Specification

Content	Specs.
Dimension.	80mm x 60mm x 25mm
Weight	100g
Network	GSM/GPRS
Band	850/900/1800/1900Mhz or 900/1800/1900Mhz
GPS chip	brand chip
GPS sensitivity	-159dBm
GPS accuracy	5m
Time To First Fix	Reacquisition    0.1s Cold status 45s Warm status  35s  Hot status  1s
Car charger	12,24V  input       5V   output
Battery	Chargeable changeable 3.7V 1100mAh Li-ion battery
Standby	50hours
Storage Temp.	-40°C to +85°C
Operation Temp.	-20°C to +55°C
Humidity	5%--95% non-condensing
