Item | Specification | Accessories | |
FM | AM | ||
Frequency Range | 87.5-108 KHz | 522-1620 KHz | 1.MP3 player 2.Operation manual |
Usable Sensitivity | ≤16d B | ≤35 d B | |
Signal/Noise Ratio | ≥50 d B | ≥45 d B | |
Stereo Channels Crosstalk | ≥40 d B | ≥35 d B | |
Distortion | ≤5% | ≤5% | |
IF Frequency | 10.7MHz | 450KHz | |
Power Supply | DC24V(20-26V) Test voltage 24.4V, negative ground | ||
Tape Speed | 4.76 CM/SEC | ||
Frequency Response | 40HZ-12000HZ(standard) | ||
Distortion | <2% | ||
Most useful Power | 45WX4 | ||
Impedance | 4~8Ω | ||
Wow and Flutter | ≤0.25% | ||
N. weight | About 1.5Kg | ||
Channel Separation | 26 dB | ||
Shape size | 188mm(W)X58.5mm(H)X161.4mm(D) | ||
Storage temperature | -20~70 | ||
Power consumption | Less 10 W | ||
Description 1. USB / SD CARD/MP3 selections Play 2. Mix input AUX IN 3. 30 perset memory stations(FM:18,MW:12) 4. Cassette playing function,Preset Scan / Auto Store Kin (AS / PS), while automatically store 6 effective radio. 5. Use the wide power supply and it is 24V±20% 6. Auto switch to MIC operative mode when input the MIC | |||





Trade Terms | FOB,EXW, CIF, C&F, DDU |
Port | Xiamen |
Shipment | Air, Sea, Express |
Payment Terms | L/C, T/T, Western Union |
Payment Condition | Payment before delievery |
Supply Capability | 5000pcs per month |
Sample Availability | Samples are available after payment |
Sample Time | 7 working days after payment |
Packing | Export standard packaging (polyform+inner box+carton), or as per your request. |
Shipping | According to customer's requirement. |
Founded in 2007,Xiamen Harine Electronics Co., Ltd. has become a professional designer and manufacturer of vehicular electronics products in Xiamen, Fujian Province, China. Harine has passed the ISO/TS16949:2009 Quality System Certification. We have been assessed as a National Hi-tech enterprise specialized in the design, production and sales of Vehicular LCD&LED monitor, Vehicular audio & video system, rear view system and so on.
With the advantage of long-period experience in vehicular products, powerful R&D team, good team sense and efficient and effective production, Harine sells the products to all over the world and has been approved to be the first choice in the field.
Presently, our factory covers an area of 3,000 square meters, has about 200 employees and 60 million RMB turnovers in 2014.
We firmly believe that quality is the most important. Most of our products have been CE Certificated, FCC Certificated or E-mark approved.
