Product Overview
Description
Product Description
Anber can supply the machine that the wire rod can feed in coil or feed in pieces.
ABE series consist of the shelf for releasing line, warp-rectified mechanism, mesh welding machine, mesh cutting machine and the shelf for mesh falling materials. It can weld O2 to O12 cold-rolled reinforcing steel with rib, steel wire as well as stainless steel wire. It adopts hydraulic pressure transmission. PLC can compile procedure controlling in order to make the distance of the mesh check accurate and operate conveniently. It can adopt once pressurization, once electrify or once pressurization, three times electrify while welding. The disk of warp release the line, warp rectifying, weft increasing materials, mesh welding, mesh cutting the falling net for the fixed length. All the actions go on successively and automatically. Many types design can satisfy different requirements. ABE series are machinery, they adopt electrical machinery that can change frequency to control electrode servo, electrical machinery control the pulling mesh. It adopts Siemens
Max. mesh width(cross wire length) | 2500mm |
Line wire spacing | 150mm, freely programmable spacing |
Cross wire spacing | 150mm, can be adjusted |
Line wire diameter and feeding | Φ5– Φ12mm, pre-cut |
Cross wire diameter and feeding | Φ5– Φ12mm, pre-cut |
Max. welding speed | 60-70 strokes per minute |
Air consumption | ≥0.8Mpa, 2m3/min |
Cooling water consumption | ≥0.3Mpa, 3m3/min |
Machine overall dimension | 40m(L) × 8m(W) × 3m(H) |
Machine overall weight | 25,000Kg |
Electronic parts specifications: | |
Numbers of welding transformer | 6 |
Numbers of air cylinder (welding press) | 6 |
Numbers of electrode | 20 |
Electric power of welding transformer | 125KVA, 220V/60Hz/3Phase |
Consumption of compressed air | ≥4 M3/min |
Contact us
Packaging & Shipping
Our Services
Warranty
Within the limits of what hereinafter set forth, ANBER undertakes to remedy all defects of the equipment attributable to its engineering, material and workmanship. Such obligation of ANBER is limited to defects that show within 12 (twelve) months from the delivery of the equipment.
To benefit from these rights, Buyer shall notify within 8 days of its discovery to ANBER, in writing, analytically and precisely, all shown defects.
Installation and commissioning
To benefit from these rights, Buyer shall notify within 8 days of its discovery to ANBER, in writing, analytically and precisely, all shown defects.
Installation and commissioning
Machine is installed and commissioned by ANBER technicians. Testing cost, travel, accommodation and meal expenses are payable by the customer, the customer will provide local engineers and staff to support the installation.
ABO- EXHIBITION
From 2013, we ABO have attend many fairs, like
"IBS&KBIS 2016" in Las Vegas, 2016 BIG5 in Dubai, we will attend annual fair to show our new type.
Here is the fair show.
ABO-CERTIFICATE
For metal beads and lath, we ABO have got many certificate,
1, rib lath sliting device patent,
2, multi angle beads slitting and rollforming patent,
3, Architrave beads patent,
4, Hi-tech enterprise cartificate
5, chinese industry-academy-research reward
Company Information
Scan with wechat Our website
Add: No. 525, Jindong road, Jinxi town, Kunshan, China
Tel: (+86)-510-88239310/88239309
Fax: (+86)-510-88237950
Web: www.china-anbermachine.com
FAQ
1. How long will your engineer reach our factory?
Within one week after machine arrival your factory.
2. How many days will you finish installing ?
Normally we will finish installation and training within 7 days. Machine installation only need 1-2 days. The left time just training your workers.
3. What should we charge for your engineer?
You should charge for the air tickets, hotel, food and also their salary 100USD one day per person.
4. How long is your machine's warranty period?
All our machine have one year guarantee, starting from the machine finished installation.
5. How could we do after one year warranty period?
We can also do service for you, but you need pay for spare parts and engineer's cost.
6. How could we do if the parts broken within warranty?
We would express the free replacement parts during the warranty date.
7. Does your engineer understand English?
Our engineer understand a little English. All our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.
8. How do we solve the machine problem after your engineer leaving?
Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our sales at any time. Our engineer will take a solution video according your description.
9. How many worker do we need running those machines?
One or two workers required for machine operation, there will be only one worker for our micro type expanded metal mesh machine within 25T punching force otherwise need two workers for hevay duty expanded metal machine.
