  • 63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V
63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V

63ZY( 63mm OD ) 100W, 150W Permanent Magnet Brushed DC Motor 12V

Share on (309902850):


Price:$12.99 - $15.99

Quantity:


Product Overview

Description



Product Description










100W, 150W Permanent Magnet Brushed DC Motor
Brushed DC Motor / PMDC Motor/Direct Current Motor
Motor Size: 60mm or 63mm Outer Diameter;
Voltage: can be customized to be 12V, 220V, 110V, etc.
Length: 105/125MM or customer's needs
Rated Speed 800rpm ~ 9999rpm
Output Power 10W ~ 150W
Optional: Planetary/Spur/Worm Gearbox; Magnetic/optical Encoder; Power-on/power-off Brake; Cable Connector
Customized shaft & flange material and dimensions as well as technical specs. are available upon requested.
Typical applications: Animal game feeder; automatic keys; key machine; electric knife sharpener

Motor Technical Data:


电机型号
Motor type
额定电压 Rated voltage
空载转速No-load speed r/min
空载电流 No-load current A
额定转速 Rated speed r/min
额定转矩 Rated torque mN.m
输出功率Output power
W
额定电流 Rated current
A
堵转转矩 Stall torque mN.m
堵转电流 Stall current A
60ZY105-2420
24
2000
0.25
1600
165
30
1.8
760
7.3
60ZY105-2430
24
3000
0.35
2400
180
45
2.2
790
11.2
60ZY105-2450
24
5000
0.5
4000
230
90
6
920
15.5
63ZY105-2420
24
2000
0.25
1600
165
30
1.8
760
7.3
63ZY105-2430
24
3000
0.35
2400
180
45
2.2
790
11.2
63ZY105-2450
24
5000
0.5
3200
230
90
6
920
15.5
63ZY125-2430
24
3000
0.5
2500
265
65
4.6
950
15.2
63ZY125-2435
24
3500
0.8
2800
320
95
6
1100
19.3
63ZY125-2440
24
4000
1.2
3200
450
150
9
1200
22.6


Certifications






FAQ


Q1: Are you a trading company or manufacturer?
A1: We are a professional OEM manufacturer.
Q2: What is your main product range?
A2: We manufacture both motors and gearboxes. Our main products are various AC/DC Planetary Gear Motors, AC/DC Right Angle Gear Motors, AC/DC Parallel Shaft Gear Motors, Small DC Motors, Compact AC Motors, Brushless DC Gear Motors, Motor Magnets, Gearboxes etc..
Q3: How about the MOQ of your motors?
A3: Customized testing samples are available before serial production.
Q4: What is the warranty period of your motors?
A4: We offer free maintenance in warranty period of one year.
Q5: Which shipping ways are available?
A5: DHL, UPS, FedEx, TNT are available for sample shipment. Sea/air/train shipments are available for serial production.
