Six-axis programmable control, XYZ+ABC (can be replaced by XYZ+ABW or XYZ+ACW)
ATC system and A, B, C axis and spindle tilt option are available to increase machine functionally
Column movable master by linear slideway on X/Y/Z
Automatic lubrication
USB port
Use a 15-inch LCD touch screen, mouse, and standard keyboard
Presented in a dialog window with 3D stereo graphic description
Machining path and graphic display
Close-loop and feedback circuit design of 0.001mm resolution numerical linear scale is adopted on the 3 axis of the machine. Such design could get precise position setting, and increase the machining precision and efficiency of ORBIT-CUT
Dialogue programming editor that provides variety of hole enlargement modes (including function of edge search, center search, reference point search)
Automatic multi-step machining is available
Automatic home search function
ARC automatic arcing adjustment
Automatic center search and offset which could search the center and the deepest point of the hole
Movement of axis linear (3 axis), arc (2 axis), spiral (3 axis) and offset
Switch function: Language switch (Chinese/English) and unit system switch (Metric/Inch)
Single side sparking of 3 axis and 6 directions (plane rotation)
Automatic programming edition function: According to the material, area, initial current and wear rate do proper adjustment
Specifications:
Item
Unit
EDM-432C
Work Table Size
mm
700*350
X/Y/Z Axis Travel
mm
400*300*350
Electrode Plate to Work Table
mm
250 / 600
Max. Electrode Weight
kg
90
Max. Workpiece Weight
kg
600
Z Axis Motor Panasonic
K
AC Servo 0.75K
Z Axis Rapid Feed Rate
m/min
5
Z Axis Cutting Feed Rate
m/min
5
Work Tank Size
mm
1100*580*370
Oil Tank Capacity
L
360
Weight of Machine Unit
kg
1300
Outside Dimensions
mm
1600*1400*2300
Standard Accessories:
Paper filters
Clamping kits
Electrode holder
Tool box
Flushing nozzle
Working lamp
Drill chuck
Optional Accessories:
Auto fire extinguisher
EROWA accessory
Dielectric cooler
C axis
Permanent magnetic table
ATC (Auto Tool Changer)
Power regulator
*If you have any further discussion or information, please feel free to contact us directly. Thank you.
