SC706 Q piano switch

Product Overview

Description





Specification:



Model: SC706-Q piano switch

Rating: 1(1)A 250VAC T85/55 1E4

1A 125VAC/250VAC

Current resistance: ≤20MΩ

Insulation resistance: ≥100MΩ at 500VDC

Dielectric strength: 1000VAC-1min

Electrical life: ≥10000 times (SEMKO)

                      ≥  6000 times

Temperature range: 0-85°C
