Aluminium alloy profile automatic door kit sliding door closer

Product Overview

Description

Aluminium alloy profile automatic door kit sliding door closer





Technical data:

Rang of the Door	Single-leaf	Double-leaf
Door leaf max weight	100kg	100kg*2
Power Supply	AC 110v-260v, 50-60 Hz
Opening  Speed	100-500mm/s (adjustable)
Closing  Speed	100-500mm/s (adjustable)
Creep speed	30-100mm/s (adjustable)
Hold-open time	0-9s (adjustable)
Hold-Close Force	70N<F<250N
Manual Pushing Force	<100N
Power consumption	60W
ambient temperature	-20-+50 C

1. Wide voltage range(AC110-260v)


2. Low power consumption when at work(60W), energy saving when at leisure(3w)


3. Concise design for easy installation.


4. 13 revisable items by the distributors.


5. Low noise design (<40db) .


6. 24v brushless DC motor, worm-geared, higher efficiency, larger torque and longer life span, fully concealed.


7. Different triggering modes, such as microwave sensor, infrared sensor, mechnical keys, finger printer, firewarning, etc...


8. Automatic locking.


9. 125mm mouting profile.


10. Track length: 2.1-6m


11. 1 million times of test passed.


12. Warranty: 12months
