TLT235SB Sale Best Price Two Post Car Lift

Product Overview

Description

TLT235SB Sale Best Price Two Post Car Lift



TLT235SB Features

1. Bilateral manual safety unlocking system.

2. The cable and oil pipe are fully concealed; with decent and elegant appearance.

3. Double hydraulic cylinder and high strength chain drive makes stable and smooth lifting and lowering.

4. Wire rope equalization system forces synchronous movement of two carriages and effectively prevents vehicle from tilting.

5. 24V low voltage control box(IP54 level)ensures operator’s safety.

6. 24V cylinder travel limit switch effectively protects cylinder and extends its lifespan.

7. Door rubber pad protects car door from being damaged in collision.

8. More lifting pads with different height meets the requirements for light lorries and SUVs.

9. Passed 115% dynamic loading test and 150% static loading test .

10. CE certificated.

11. Symmetric and asymmetric installation types are optional. (For SC model)

TLT235SB  Parameters

1. Rated load: 3500kg
2. Lifting height:1850mm
3. Initial height:110mm
4. Lifting time: 50s
5. Lowering time: 20s 40s
6. Passing width: 2486mm
7. Overall width: 3370mm
8. Overall height: 2860mm
9. Motor power : 2 .2kw
10. Motor voltage: 3 phase/380v or Single phase/220V
11. Working noise: 75dB(A)
12. Working oil pressure:16M Pa
