roller press used in cement grinding station

Product Overview

Description

I. Technical parameter

1. Equipment name: HFCG140-80 rolling machine

2, Usage: It is used for crushing cement clinker

3. Amount: One unit

4. Name of material: Cement, clinker and so on

5. Integrated moisture: ≤1~1.5%

6. Feed size: Dmax≤80mm

7. Discharge size: less than 2mm,accounting for above 60%

8. Production capacity Average 250~360 t/h

Maximum 360t/h

9. Working system Continuous

10. Power supply method voltage 10000V

Model of motor YR5001-8

11. Arranging method Indoor

12. Required power 2×500 kW

13. Diameter of roller 1400mm

14. Width of roller 800mm

15. Rotary speed of roller 23.8 r/min

16. Weight of equipment ****.0 t
