Automated DCP fire extinguisher filling machine/DCP powder extinguisher filling machine/powder filler GFM 2

Product Overview

Description

Automated DCP fire extinguisher filling machine/DCP powder extinguisher filling machine/powder filler GFM 2



1, GFM powder filler (patent number:ZL01275908.2)

 is a new product developed and designed by our factory in combination with the characteristic of actual filling with reference to the advantages of its counterparts at home and abroad. Powder is rapidly absorbed into the cylinder to be filled by vacuum jet current. It is equipped with T3806 weight display of high precision and MP-T printer. The filling is automatic and quantitative. The residual dust on the filter is cleared by use of the negative pressure produced by vacuum. As it integrates electronics, electrical device and machinery into one entity, labor intensity is lowered and work environment improved. It is characterized by small volume, light weight, lower energy consumption, easy movement, simple operation and longer service life. So it is specially suitable for powder filling of fire extinguisher and also ideal for other powder filling sector.

2, Main Technical Parameters

Volume: Length ×Width ×Height (1130mm×520mm×1350mm)

Weight: 200kg

Voltage: AC 380v/220v 50Hz

Power: 0.55KW

Filling precision: 1kg≤+0.15

Use:

In GFM powder filler, Y series motor of 0.55 KW is used as motive power to drive 2X vacuum pump, which can both satisfy the powder filling requirements of various fire extinguishers and suck powder out of the cylinder of the used extinguisher (refer to Figure 2). The filler adopts the filling method integrating speed and accuracy. Two filling modes, namely, continuous and operating are available, which are fit for manufacturers.



3, Operation for use:

Pipeline connection

First have the powder suction pipe (Figure 1-15) properly connected to conical powder storage bucket in the warehouse (The conicity of the powder storage bucket is usually 3:2 according to Figure 2 and the user may determine its size in terms of the production capacity at its discretion). VI. Possible Faults and Their Removal

Symptoms	Troubles	Corrections
Motor doesn’t run after energization	Leakage protector is off	Check if leakage occurs and energized after removal
	Fuse is open or loose	Replace and tighten
	Heat relay is open	Check if damage occurs and reset by pressing the reset button
	Contactor is broken	Repair or replace
	f	Properly connected



4, Maintenance

1.  No impurities are allowed in the powder being sucked by the suction pipe;

2.  No powder in excess of the moisture percentage specified and corrosive powder shall be used to prevent equipment from being damaged;

VIII. Packing List



Serial No.	Name	Size	Quantity	Unit
1	Powder filler	GFM	1	Unit
2	Electronic scale bench	T3806	1	Unit
3	End cap for filling	120mm	1	Piece
4	Suction pipe	15mm	4	Meter
5	Valve	65mm	1	Piece
6	Discharge outlet		1	Piece
7	Rubber gasket	65mm	2	Piece
8	Plain rubber gasket	25mm	5	Piece
9	Certificate of conformity	GFM	1	Copy
10	Directions for use	GFM	1	Copy



5,  GFM-8 automated fire extinguisher powder filler/automated fire extinguisher powder filling machine

designed by our company our factory hasmore than 30 years experience in fire fighting industry.

GFM-8 automated fire extinguisher powder filler advantage:
1. Automatic cleaning: Press the button only, the filler will clean thoroughly of itself.
2. Filling continuously: After filled a fire extinguisher, the work need not restart the powder outlet, in 5 seconds (this time can be adjusted by user), powder will flow out automatically.
3. Anti-corrode: Stainless powder storage cylinder.
4. Two style powder outlet: Powder outlet 1# makes filling work much easy, it avoids to waste time on aim the powder outlet to fire extinguisher cylinder inlet.
5. Powder recycles function.
GFM-8 automated fire extinguisher powder filler Feature:
1. Automatic control whole procedure:
Sucking powder from warehouse or other fire extinguisher, automatic filling, stop and cleaning of filter.
2. Accuracy:
4. Economy
Only one worker is needed to finish whole filling action, cylinder movement.
5. Automatic Cleaning
