Трехфазный генератор переменного тока

Product Overview

Description







THREE PHASE ALTERNATOR







Detailed Product Description

Brushless alternator/power Alternator/dynamotor/Generator/brushless dynamo/

This series generators adopt international advanced technologies of manufacturing
electric machinery, suitable for marine lighting. With switch box, it is to easy
operating.
Specifications:

1) Rated output: 8 to 1000kW

2) Rated frequency: 50/60Hz

3) Rated speed: 1,500/1800rpm

4) Rated voltage: 400V

5) Three-phase four-wire

6) Protection: IP21 or IP22

7) Insulation: class F/H

8) Standard: international electrician committee command standard IEC34, international
   standardization organization: command standard, ISO8528 NEMA standard
9) Engine can be connected with steel or flexible materials

10) Steel frame: cast-iron cover

11) Excellent silicone steel chip

12) Imported bearings. You could choose one bearing or two bearings

Serviceable environment condition
1. Temperature of ambient air ≤40°C
2. Altitude above sea level ≤1000m
3. Relative humidity of ambient air :90%
Stable novel structure
1.Intergral salient-pole rotor. Special designed for iron-core ventilation. Solid windings and a good
performed thermal radiator.
2. Cylinderical steel base. Novel and delicate appearance.
3. Bearing: single bearing or two bearing
4. small volume and light weight
