4.5 digit DC digital VOLTMETER VOLTAGE METER Red LED display
- Category: >>>
- Supplier: Shaanxi Xieli Photo Electric Instrument Co. Ltd.
Share on (344111667):
Product Overview
Description
4.5 digits DIgital Voltmeter:
Tapping size(mm):76mm×39mm
Dimension(mm):w79mm×h42.5mm×d25.5mm
Specifications:
Digital ampere meter Digit DC5V
More than 50,000 hours long life
4 1\\2 digit 15mm red led display
Digital ampere meter 4 1\\2 Digit DC5V
Technical index:
Digit display: 19999
Operating temperature:0~50
Relative humidity:20%~80%
Power supply:DC5V
Installation method:Inlay
Tapping size:76 X 39 (mm)
Dimension: (W) 79mm X (H) 42.5mm X (D) 25.5mm
Model | Digit | Range | Resolution | Accuracy | Resistor | Max input voltage | Power | |
XL5145V-1 | 4½ | ±199.99mV | 0.01mV | ±0.05 % +2 | 100MΩ | ±5V | DC 5V | |
XL5145V-2 | 4½ | ±1.9999V | 0.1mV | ±0.05 % +2 | 100MΩ | ±30V | DC 5V | |
XL5145V-3 | 4½ | ±19.999V | 1mV | ±0.05 % +2 | 4.5MΩ | ±250V | DC 5V | |
XL5145V-4 | 4½ | ±199.99V | 10mV | ±0.07 % +2 | 4.5MΩ | ±500V | DC 5V | |
XL5145V-5 | 4½ | ±500V | 100mV | ±0.7 % +2 | 4.5MΩ | ±600V | DC 5V |
