automatic rewinding small toilet roll and kitchen towel tissue paper making machine

      Model

HX-GS-2000 Toilet Roll&Maxi Roll Rewinding Machine

Jumbo Roll Max Width

1800mm (Other size can be specified)

Jumbo Roll Diameter

Φ1100mm(Other size can be specified)

Jumbo Roll Inner Diameter

3inches(76.2mm) (Other size can be specified)

Perforation Distance

4 anvil Blades(115mm)(Other size can be specified)

Finished Product Diameter

Φ80~φ280mm

Finished Product Core Diameter

φ38~φ76mm

Embossing Unit

With one set steel to rubber embossing

Production Speed

0~230m/min

Program Controller

PLC(Delta)

Unwind Stands

1 or 3 Stands(Need to be specified)

Pneumatic System

3HP Air Compressor, Minimum Pressure: 5kg/cm 2Pa(Provide by user)

Main Power

18KW

Dimension

7800*3000*1720(L*W*H)

Weight

About 12T (All machine 40mm wallboard type institutions)

Jumbo Roll Layers

1~3layers,14~30gsm

Embossment (can be specified)

Big diameter rollers,Steel to Rubber, double embossing(steel to rubber)

Voltage

380V 50HZ(can be specified)
